Technical Specifications

Engine & Drivetrain

• Engine Model: Dongfeng Cummins 4BTAA3.9-C130-II

• Rated Power: 135HP (96kW) @ 2200 rpm

• Transmission: Electro-hydraulic powershift, 6 forward / 3 reverse gears

• Drive System: Rear-wheel drive with front-wheel assist; three-stage drive axle with self-locking differential

• Steering: Articulated frame + front-wheel steering for minimum turning radius of 6.8m

Blade & Working Equipment

• Moldboard Width: 3,658 mm (12 ft)

• Blade Lift Height: 450 mm above ground

• Max. Blade Cut Depth: 500 mm below ground

• Blade Tilt Angle: ±10°

• Circle Rotation: 360° continuous

• Hydraulic Control: Full hydraulic, pilot-operated joystick system

Dimensions & Weight

• Overall Length: 7,850 mm

• Overall Width: 2,400 mm

• Overall Height: 3,200 mm

• Operating Weight: 11,000 kg

• Fuel Tank Capacity: 200 L

Key Operational Advantages

1. Precision Grading Performance

The GR135 delivers ±3mm surface accuracy over 3m distance, ideal for final road surfacing, sports field preparation, and airport runway maintenance. The fully hydraulic blade system enables smooth, responsive control even during fine grading operations.

2. Urban & Rural Versatility

✅ Compact Maneuverability: Articulated frame + short wheelbase allows operation in narrow streets and confined job sites
✅ Multi-Task Capability: Equipped for road grading, slope shaping, ditch digging, snow plowing, and light dozing
✅ Low Noise & Emissions: Meets Tier III standards with noise levels under 80 dB(A) at operator position

3. Operator Comfort & Safety

• Fully adjustable suspension seat with integrated controls

• Ergonomic layout with clear instrument panel and low-effort joysticks

• ROPS/FOPS-certified cabin with optional air conditioning

• Excellent all-around visibility with large windshield and rearview camera option

Reliability & Support Package

Quality Assurance

• Hydraulic System: Uses Bosch Rexroth or equivalent international brand components

• Frame Structure: High-strength steel with stress-relieved welding for long service life

• Certifications: CE, ISO 9001, and national type approval

After-Sales Support

• Warranty: 18 months on major components (engine, transmission, hydraulic system)

• Training: Free operator and maintenance training via video or on-site

• Spare Parts: Common wear parts stocked in Dubai, Lagos, and Jakarta warehouses

• Technical Assistance: Direct WhatsApp support line to XCMG-certified engineers

Delivery Process

1. Inquiry: Message “GR135 SPEC” to William Du on WhatsApp (+86 186 6977 8647)

2. Configuration Review: Receive machine data sheet and optional attachments list

3. Pre-Shipment Inspection: Live video call to witness factory test run

4. Shipment: Container or RoRo loading within 30–40 days after order confirmation

Current Availability: Units with August–September 2025 build dates available for immediate allocation

Contact: William Du
Authorized Distributor For: XCMG road machinery in Africa, Southeast Asia & Middle East
WhatsApp/WeChat: +86 186 6977 8647
