Basic parameters

Engine model

6BTA5.9-C180-Ⅱ

Rated power/speed

132kW/2200rpm

Overall dimensions (Standard configuration)

8900×2625×3420mm

Overall weight (Standard configuration)

15000kg

Tire specification

17.5-25

Ground clearance (Front axle)

430mm

Wheel tread

2156mm

Span between front and rear axles

6219 mm

 Space of middle and rear wheels

1538 mm

Performance parameters

Forward speed

5、8、11、19、23、38km/h

Reverse speed

5、11、23km/h

Traction force f=0.75

≥77kN

Maximum gradeability

≥25%

Inflation pressure of tires

260kPa

Working system pressure

16MPa

Transmission pressure

1.3—1.8Mpa

Working parameters

Maximum steering angle of front wheels

±50°

Maximum inclination angle of front wheels

±17°

Maximum swing angle of front axle

±15°

Maximum swing angle of balance box

15°in front and 15°at back

Maximum steering angle of frame

±27°

Minimum turning radius

7.3m

Blade

Maximum lifting height

450mm

Maximum shoveling depth

500mm

Maximum lateral inclination angle

90°

Cutting angle

28°—70°

Slewing angle

360°

Length× chord height

3660×610mm

Filling capacity

Coolant

50L

Fuel tank

280L

Engine

24L

Transmission

38L

Balance box

46L

Drive axle

28L

Hydraulic oil

110L
