SITRAK 8x4 Chassis Mounted ZOOMLION 62M Boom Concrete Pump Truck
No.: KL260310WJX3
Vehicle Type: Concrete Mixer Truck Algeria
Brand Name: ZOOMLION
Person in charge: Stacy Wong
Cel: 8617657099215
Whatsapp: 0086 17657099215
E-mail: sales5@chinatruck.cc
FREE GET QUOTE
Details
SITRAK 8x4 Chassis Mounted ZOOMLION 62M Boom Concrete Pump Truck
Key Features
✅Proven Performance: Built on the SINOTRUK SITRAK platform, featuring high-torque engine that ensures powerful climbing ability and fuel efficiency even under full load.
✅Ultra-Long Vertical Reach: With a maximum vertical reach of 62 meters, this pump truck is ideal for high-rise building construction, tall bridges, and industrial complexes.
✅Remote Control: Includes a wireless remote control unit, allowing the operator to stand at the optimal vantage point for precise pouring, improving both safety and accuracy.
✅Driver Comfort: Ergonomically designed cab with power steering, air conditioning, and a fully digital instrument panel reduces driver fatigue during long working hours.
SITRAK 8x4 Chassis Mounted ZOOMLION 62M Boom Concrete Pump Truck
Specifications:
| Pump system | Maximum theorical output (m3/h) | 180 |
| Maximum theorical pressure on concrete (MPa) | 11.3 | |
| Rated working pressure (MPa) | 42 | |
| Pumping frequency (min-1) | 28 | |
| Hopper Volume (L) | 700 | |
| Filling height (mm) | 1540 | |
| Boom | Model | 62X-6RZ |
| Reach height (m) | 61.2 | |
| Slewing radius (m) | 56 | |
| Reach depth (m) | 44.3 | |
| Chassis specifications | Model | ZZ5466V516MF1 |
| Wheelbase (mm) | 1950+5400+1400 | |
| Engine model | MC11.46-61 | |
| Rated power kW/（r/min） | 341/1900 | |
| Max. torque N.m/（r/min） | 2200/1000-1400 | |
| Emission Standard | Euro Ⅵ | |
| Overall weight (kg) | 45870 | |
| Outline dimension (mm) | 14920×2550×3965 |
This vehicle is designed for complex urban environments and large-scale infrastructure projects, this 62-meter concrete pump truck offers exceptional reach, high output, and superior stability.
Contact us for pricing and configuration options！
