5 CBM Diesel Rear-Loader Garbage Compactor Truck – Mini Refuse Collector for Urban Waste for Sale
No.:
Vehicle Type: Garbage Truck
Brand Name: ISUZU
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
5 CBM Diesel Rear-Loader Garbage Compactor Truck – Mini Refuse Collector for Urban Waste for Sale
Key Features
• Compact Footprint – 6.45 m long, 2.05 m wide, 2.57 m high; ideal for narrow alleys, estates and small transfer stations
• High Compression – 12 t crushing force, 1/3–1/4 volume reduction doubles payload vs. open trucks
• Leak-Proof Tank – 4 mm carbon-steel body, fully welded seams, integral 80 L sewage sump prevents roadside spills
• Rear Loader – Hydraulic bin lifter accepts 120 L / 240 L / 660 L plastic or steel bins; optional bucket system
• One-Operator PLC – Dual control panels (rear + cab), automatic loading / compressing / ejecting, cycle ≤14–18 s
• Mini Chassis – 2-axle, 98 HP Euro-4 diesel, 5-speed manual, 90 km/h max, 7.00-15 tyres, ABS, A/C cab
Specifications
| Item | Parameter |
|---|---|
| Overall Dimension | 6 450 × 2 050 × 2 570 mm |
| Gross Vehicle Weight | 7 300 kg |
| Curb Weight | 5 170 kg |
| Payload (waste) | 2 000 kg |
| Wheelbase | 3 360 mm |
| Front / Rear Axle Load | 2 500 kg / 4 800 kg |
| Engine | 98 HP Euro-4, 4-cyl, 2.771 L |
| Gearbox | 5 fwd + 1 rev |
| Max Speed | 90 km/h |
| Tyres | 7.00-15, 6 + 1 spare |
| Fuel Tank | 100 L |
| Cab | LHD, 3 seats, A/C, radio, ABS |
| Garbage Bin | 5 m³ (5 000 L) |
| Tank Material | 4 mm carbon steel, leakage-proof |
| Compression Ratio | 1/3–1/4 |
| Crushing Force | 12 t |
| Control | Dual PLC + manual override |
| Loading Method | Rear bin lifter (120/240/660 L) |
| Discharge | Hydraulic ejector plate |
| Sewage Tank | 80 L integral |
| Cycle Time | ≤14–18 s |
| Colour | Customer choice |
| Logo | Custom decals available |
Typical Applications
• Urban residential waste collection
• Commercial districts & shopping centres
• Hospital & campus waste removal
• Construction site light debris
Optional Upgrades
• 7 m³ or 8 m³ tank upgrade
• 115 HP Euro-5 engine
• Stainless-steel 304 body for corrosive waste
• Rear camera & ultrasonic sensor
• Remote wireless control
Contact us for pricing and configuration options!
Contact: william
Phone/WhatsApp/WeChat: +86 18669778647
Email: Sales22@chinatruck.cc
