FAW 4×2 95 km/h Euro-VI 110 HP Manual 5-Speed 2 t/2.7 t Axles 22-28 m Straight-Arm TelescopiFAW 4×2 95 km/h Euro-VI 110 HP Manual 5-Speed 2 t/2.7 t Axles 22-28 m Straight-Arm Telescopic Boom Hydraulic Aerial Cage Truck for Salec Boom Hydraulic Aerial Cage
No.:
Vehicle Type: Aerial Work Truck
Brand Name: FAW
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
FAW 4×2 95 km/h Euro-VI 110 HP 5-speed manual 2 t/2.7 t axles 22-28 m straight-arm telescopic boom aerial cage truck—factory-built with 360° continuous rotation, CAN-bus + wireless remote, 1200×700×1150 mm stainless-steel cage.
Key Features
• 22-28 m Working Height – four-section hexagonal boom, synchronous telescopic, stepless speed
• 360° Continuous Rotation – slewing bearing, hydraulic motor, wireless remote control
• Euro-VI Power – FAW Q23-110E60, 110 HP, 2300 ml, 95 km/h max
• 5-Speed Manual – CA 5-speed with overdrive, reliable uphill drive
• 2 t/2.7 t Axles – leaf-spring suspension, 6.50R16LT tyres (6+1)
• CAN-Bus Control – digital display, fault diagnosis, stepless boom speed
• Safety – front V + rear H outriggers, individual adjustment, emergency manual pump
• Fast Delivery – 15-20 working days, 12-month warranty
Specifications
| Item | Value |
|---|---|
| Drive | 4×2 |
| Engine | FAW Q23-110E60, 110 HP, Euro-VI |
| Gearbox | 5-speed manual |
| Front Axle | 2 t |
| Rear Axle | 2.7 t |
| Cage Load | 200 kg |
| Max Speed | 95 km/h |
| Boom Form | 4-section hexagonal telescopic |
| Working Height | 22-28 m |
| Rotation | 360° continuous |
| Outriggers | Front V + rear H, individual control |
| Control | CAN-bus + wireless remote |
| Overall Size | 5998×2050×3050 mm |
| Wheelbase | 2800 mm |
| Tyres | 6.50R16LT 12PR, 6+1 |
| Electric System | 24 V |
| Production Cycle | 15-20 days |
| Warranty | 12 months |
Optional Heights
• 22 m, 24 m, 28 m boom lengths available on same chassis
Contact us for pricing and configuration options!
