SHACMAN F2000 18cbm Dump Trucks 25t 6x4 290hp Diesel Tipper Truck

No.: David-0730

Vehicle Type: Dump Truck

Brand Name: SHACMAN

Shacman Trucks

Person in charge: David Ma

Tel: 0086 532 6608 7516

Cel: 0086 181 5320 9783

E-mail: sales20@chinatruck.cc

FREE GET QUOTE

Details

Person in charge: Mr.David Ma

Tel: 0086-532-66087516

Cel: 0086-18153209783

E-mail: sales20@chinatruck.cc

SHACMAN F2000 Dumper Trucks 25t 6x4 290hp Diesel Dump Truck


SHACMAN

F2000

6*4

dump truck

SX3251DM384

Traction type

LHD

Drive System

6x4

Cabin

F2000 Flat Cabin, one sleeper, Air Conditioner

Engine

Brand

WEICHAI

Model

WD615.50  EURII

Rated power

290hp

Engine displacement

9.726 liters

Gearbox

FAST 9 Speeds (9JS135)

Clutch

Ф430 Diaphragm type

Steering

ZF technology

Axle

Front

7.5 Ton Man axle

Rear

13 Ton STR double reduction axle, ratio:5.73

Max. running speed (km/h)

77

Tire

12R22.5 tubeless tire(10+1)

Fuel tank

380L

Kerb weight (kg)

12100

Total mass (kg)

25000

Wheel base (mm)

3800+1350

Overhang (mm) (front/rear)

1525 / 1654

Track (mm) (front/rear)

1939/1860

Approach / departure angle(°

20/20

DimensionsL*W*H(mm)

Overall

8329x2490x3450

Dump body

5200x2300x1500(18cbm)

Thickness (mm

Bottom 8 , side 6

Hydraulic lifting system

 Middle lifting

Options
