Technical Specifications

Engine & Power System

• Engine Model: Yuchai YC6L260-33

• Rated Power: 256HP (188kW) @ 2200 RPM

• Fuel Tank Capacity: 400L (continuous operation for 8+ hours)

• Cooling System: High-efficiency radiator with automatic dust removal

• Emission Standard: Tier 3 compliant with EGR technology

Harvesting System

• Working Width: 8.2 meters (8-row configuration)

• Cutter Bar Type: Reversible knife sections with quick replacement

• Reel Type: Hydraulic adjustable diameter auger reel

• Feeding Mechanism: Dual-conveyor automatic feeding system

• Grain Tank Capacity: 6,500 liters with hydraulic unloading auger

Dimensions & Mobility

• Overall Length: 8,600mm

• Overall Width: 4,980mm

• Overall Height: 3,850mm

• Wheel Configuration: 4x4 wheeled drive with differential lock

• Ground Clearance: 450mm (adjustable)

• Turning Radius: 6.5m (with brake steering)

• Transport Speed: 30 km/h

Operational Advantages

1. One-Pass Harvesting Efficiency

The 4YZL-8F1W completes harvesting, threshing, cleaning, and grain collection in a single pass, eliminating multiple field operations. The 8.2m header width covers 1.5 hectares per hour in wheat fields, reducing fuel consumption by 35% compared to traditional two-pass methods.

2. Intelligent Monitoring Systems

✅ Grain Loss Detection: Real-time sensors monitor grain loss at separator and cleaning shoe, automatically adjusting rotor speed and fan airflow
✅ Crop Flow Management: Load-sensing hydraulics adjust cylinder speed based on crop density, preventing blockages in heavy maize conditions
✅ Yield Mapping: GPS-integrated yield monitor creates field productivity maps for precision agriculture planning
✅ Remote Diagnostics: 4G connectivity allows technical support team to monitor machine health and prevent downtime

3. Crop Versatility

The modular header system enables quick conversion between crops:

• Maize/Corn: 8-row header with row cleaners and stalk rolls (included)

• Wheat/Barley: Wide-cut platform header (optional)

• Soybean/Rice: Flexible cutter bar configuration (optional)

• Cotton: Specialized cotton picking attachment (available Q4 2024)

Reliability & Support Package

Comprehensive Warranty Coverage

• Engine & Transmission: 24 months or 1,500 operating hours (whichever comes first)

• Harvesting Components: 24 months on rotor, concaves, and cleaning system

• Electronics: 18 months on monitoring systems and displays

• Structural Elements: 36 months on frame and header mounting points

Operator Support System

• Training Program: On-site operator training (3 days) included with every machine

• Digital Resources: Bilingual operation manuals (English/French) with video tutorials

• Spare Parts Network: 250+ critical components stocked in Johannesburg, Nairobi, and Addis Ababa

• Seasonal Support: Harvest season technical teams deployed to major farming regions August-November

Deployment Timeline

1. Initial Consultation: WhatsApp field conditions and crop types to William Du (+86 186 6977 8647)

2. Configuration Finalization: Receive machine specification sheet within 24 hours

3. Pre-Delivery Testing: Video documentation of field testing under actual harvesting conditions

4. Delivery & Setup: Factory to farm delivery within 45 days including on-site commissioning

Current Production Status: 12 units in final assembly phase with August 2024 production dates

Contact: William Du
Verified Supplier For: Commercial farming operations in Nigeria, Kenya, Zambia, and Ethiopia
WhatsApp/WeChat: +86 186 6977 8647
