FOTON Aumark S 12m Aerial Working Platform Bucket Lift Truck
No.: KL250820WJX15
Vehicle Type: Telescopic Handler
Brand Name: FOTON
Person in charge: Stacy Wong
Cel: 8617657099215
Whatsapp: 0086 17657099215
E-mail: sales5@chinatruck.cc
FREE GET QUOTE
Details
FOTON Aumark S 12m Aerial Working Platform Bucket Lift Truck
This truck is incredibly versatile and is commonly used for:
Street light installation and maintenance
Tree trimming and pruning
Building facade repair and cleaning
Signage installation and billboard maintenance
Telecommunication and power line maintenance (secondary work)
Window installation and repair
Fire rescue and emergency services support
FOTON Aumark S 12m Aerial Working Platform Bucket Lift Truck
FOTON Aumark S 12m Aerial Working Platform Bucket Lift Truck
FOTON Aumark S 12m Aerial Working Platform Bucket Lift Truck
Specifications:
| Brand | FOTON |
| Model | Aumark S |
| Overall dimensions (mm) | 5875×2030×2230 |
| Wheel base(mm) | 3360 |
| Curb weight(kg) | 2600 |
| Gross vehicle weight(kg) | 6495 |
| Persons in cab | 3 |
| Max. speed(km/h) | 95 |
| Engine Model | F3.8s3141 |
| Emissions standards | Euro3 |
| Displacement(L) | 3.76 |
| Rated Power(kw/rpm) | 105 |
| Max torque (N.m/rpm) | 450 |
| Gearbox Model | 6TS55 |
| Front axle | 2.2T |
| Rear axle | 5.5T |
| Bucket size(mm) | 1200x600x1100 |
| Boom | Two-section folding arm |
| Working height of bucket | 12.3m |
| Maximum working range of working bucket | 6m |
| Rated load of working bucket | 200Kg |
| Rotation angle | ±360° continuous |
| Working range at maximum working height of working bucket | 3m |
| Working height when working bucket maximum working range | 7.3m |
| Lifting time of working platform | 80~130s |
| Swing speed | 0~2 r/min |
The FOTON Aumark S 12m Aerial Working Platform Bucket Lift Truck is a versatile and robust solution designed for efficient and safe operations at height. Built on the reliable and cost-effective FOTON Aumark S commercial truck chassis, this vehicle integrates a high-performance aerial work platform (AWP), making it an ideal choice for a wide range of industries including utilities, municipal maintenance, construction, landscaping, and signage installation.
Contact us for pricing and configuration options！
Contact: Stacy
Phone/WhatsApp/Wechat: +86 17657099215
Email: Sales5@chinatruck.cc
