XCMG MOTOR GRADER GR180 WITH CUMMINS ENGINE AND ZF GEAR BOX FOR SALE
No.: bella21
Vehicle Type: Motor Grader
Brand Name: XCMG
Person in charge: Marc Zhou
Cel: 8617664086916
Whatsapp: 8617664086916
E-mail: sales3@chinatruk.cc
FREE GET QUOTE
Details
XCMG GR180 Motor grader
1. CUMMINS electronical injection diesel engine (Tier 3)
2. ZF power shift gearbox
3. CE certification
•CUMMINS electronical injection diesel engine (Tier 3) features low noise and emission.
•ZF electro-hydraulic control power shift gearbox guarantees flexible and convenient operation.
•With NO-SPIN self -locking differential, the three-way drive axle provides reliable and stable drive.
•Double-circuit travel braking hydraulic system is safe and reliable.
•With ROPS&FOPS, the cab is equipped with the electric washing window equipment and clear fog equipment. The air-conditioning can exchange the air automatically.
•The front wheel hydraulic auxiliary drive system is interlocked with the rear wheel gear. The machine can get 6-wheel, 4-wheel and 2-wheel drive.
•The machine passes the CE certification, and meets the requirement of Europe safety and environmental care.
•Optional devices: front bulldozing plate, front harrow, rear scarifier, rotating ball disk and automatic leveling system.
XCMG Motor grader Technical Parameter
GR180 | |
Engine rated power/rev | 140kW/2200rpm |
Dimension | 8900×2625×3470mm |
Weight | 15400kg |
Distribution weight of front wheel | 4620kg |
Distribution weight of rear wheel | 10780kg |
Min. clearance | 430mm |
Front and rear axle clearance | 6219 mm |
Front and rear axle clearance | 1639mm |
Max. steering angle of front wheel | ±50° |
Max. inclination angle of front wheel | ±17° |
Max. swing angle | ±15° |
Frame steering angle | ±27° |
Min. turning radius | 7.3m |
Traction | ≥79kN |
Gradeability | 20% |
Forward speed | 5,8,11,19,23,38 km/h |
Reverse speed | 5,11,23 km/h |
Blade | |
Max. lifting height | 460mm |
Max. Digging Depth | 500mm |
Max.inclination angle | 90° |
Cutting angle | 28°—70° |
Rotating angle | 360° |
Blade length × arc height | 3965×610mm |
Main technical parameter of optional working devices
GR180 | ||
Front bulldozing plate | ||
Bulldozing width | 2744mm | |
Digging depth | 110mm | |
Rear scarifier | ||
Gear no. | 5 | |
Digging depth | 350mm | |
Scarifying width | 2095mm | |
Gear no. | ||
Digging depth | 2 | |
Scarifying width | ||
Medium harrow | ||
Gear no. | 11 | |
Digging depth | 280 mm | |
Scarifying width | 1325 mm | |
