XC7-TV12 premium crawler skid steer loader delivers unmatched stability with 110L fuel tank for 12+ hours continuous operation. Features zero-radius turning, 3850kg operating weight, and 74kW engine for demanding construction tasks. Compatible with 30+ attachments including augers, breakers, and buckets. Reinforced chassis designed for 15-year service life in harsh environments. Full maintenance program and global parts support. WhatsApp William (+86 186 6977 8647) for technical specifications and delivery options.

Technical Specifications

Engine and Performance
Engine Model: Deutz TD2.9
Power Output: 74 kW at 2200 rpm
Torque: 340 Nm at 1500 rpm
Fuel System: Common rail injection
Fuel Capacity: 110 liters
Cooling System: Liquid-cooled with reversible fan
Operating Weight: 3850 kg
Travel Speed: 0-8 km/h variable
Gradeability: 60 percent slope
Traction Force: 58 kN
Noise Level: 102 dB at operator position

Hydraulic System
Main Pump Type: Axial piston variable displacement
System Pressure: 21 MPa
Hydraulic Flow: 85 L/min
Auxiliary Circuit Flow: 70 L/min
Oil Tank Capacity: 115 liters
Filtration: Dual stage with 10 micron primary filter

Working Dimensions
Bucket Capacity: 0.45 cubic meters
Maximum Lift Height: 3200 mm
Dump Height: 2400 mm
Dump Reach: 750 mm
Turning Radius: Zero degrees pivot turn
Length with Bucket: 3380 mm
Width: 1580 mm
Height: 2150 mm
Track Width: 400 mm
Ground Clearance: 220 mm
Ground Pressure: 0.28 kg/cm2

Durability Features
The XC7-TV12's structural components utilize high-strength steel (Q345B grade) with strategic reinforcement at stress points. The undercarriage features sealed track rollers with extended service intervals of 1500 hours. Critical pivot points incorporate replaceable bushings rather than direct metal-to-metal contact. Hydraulic cylinders include chrome-plated rods and double-sealing systems to prevent contamination. The fuel tank is constructed from anti-corrosion treated steel with integrated baffles to reduce sloshing during operation. Electrical components are housed in waterproof enclosures with IP65 rating protection.

Maintenance Advantages
All daily maintenance points are accessible from ground level without climbing on the machine. The hydraulic oil sampling port allows for condition monitoring without system shutdown. Engine oil and filters can be changed in under 15 minutes by a single technician. Track tension adjustment requires no special tools and can be performed in the field. The XC7-TV12 includes a digital maintenance reminder system that alerts operators when service intervals are approaching based on actual operating hours.

Attachment Versatility
Standard quick-attach system complies with ISO 24595 safety requirements. Auxiliary hydraulic circuits can be programmed for specific attachments through the onboard display. Common attachment options include:

• General purpose bucket (0.45 m3)

• Rock bucket with reinforced cutting edge

• Hydraulic breaker (1800 impacts per minute)

• Earth auger (200-1200mm diameter)

• Pallet forks (1200kg capacity)

• Landscaping rake with replaceable tines

• Trencher attachment (600mm depth capacity)

• Snow blower (1500mm width)

Operational Efficiency
The XC7-TV12's large fuel tank reduces refueling frequency to once per shift in most applications. Electronic engine management optimizes fuel consumption based on load demands, reducing consumption by 12% compared to conventional systems. The hydrostatic transmission provides smooth power delivery with no shock loading on drivetrain components. Operator comfort features include suspended seat with 4-point adjustment, low-effort joystick controls, and excellent all-around visibility.

Warranty and Support
Standard warranty covers 24 months or 3000 operating hours on structural components. Powertrain warranty extends to 36 months with scheduled maintenance compliance. Global parts distribution network ensures 95% parts availability within 72 hours in major markets. Technical support available via video call for troubleshooting assistance. Factory-certified training programs available for operators and maintenance personnel.

Shipping and Delivery
Machines are prepared for export with corrosion inhibitor treatment on all exposed metal surfaces. Hydraulic systems are filled with preservation fluid for long-term storage. Units can be containerized (two units per 40-foot high cube container) or shipped as breakbulk cargo. Export documentation includes CE certification, operation manuals in multiple languages, and parts catalog.

Contact Information
William
International Equipment Specialist
WhatsApp/WeChat: +86 186 6977 8647
Email: sales22@chinatruck.cc

When contacting William, please provide:

• Required quantity and delivery timeline

• Intended applications and working conditions

• Specific attachment requirements

• Destination port or delivery address

All inquiries receive response within 4 business hours. Factory visits can be arranged with 14 days advance notice. Bulk purchase discounts available for orders of 5 units or more. Financing options available through partner institutions in select markets.
