SHACMAN SAGMOTO X9 4×2 160 HP Euro II 4.2 m Dump Tipper Truck 6.33 T Rear Axle for Sale
No.:
Vehicle Type: Light Tipper Truck
Brand Name: SHACMAN SAGMOTO
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
SHACMAN SAGMOTO X9 4×2 160 HP Euro II 4.2 m Dump Tipper Truck 6.3 T Rear Axle for Sale
Key Features
Chassis: SAGMOTO X9 4×2 LHD, 3 800 mm wheelbase, 800 × 250/7+4 mm frame.
Engine: Yuchai YC4E160-33 160 HP Euro II, 8JS85E-C 8-speed gearbox + QD40J PTO.
Rear axle: 10 T ratio 6.33, suspension 9/11+8 leaf springs, 130 L aluminum fuel tank.
Dump body: 4 200 × 2 300 × 1 000 mm T700 steel, 4 mm floor / 3 mm sides, single 160 cylinder lift.
Cab: X9 semi-high with A/C, 4.3-inch TFT cluster, power windows, halogen headlights, 100 Ah battery.
Tyres: 10.00R20 16PR + spare, English logo, no Xuande badge, silver lettering.
Specifications
| Item | Specification |
|---|---|
| Model | SX3183F2Y16F3810 |
| Engine | Yuchai YC4E160-33 160 HP Euro II |
| Gearbox | 8JS85E-C 8-speed |
| Rear Axle | 10 T, ratio 6.33 |
| Wheelbase | 3 800 mm |
| Dump Body | 4.2 × 2.3 × 1.0 m T700 steel |
| GVW | 18 t |
| Curb Weight | 7.17 t |
| Payload | 10 t |
| Max Speed | 90 km/h |
| Tyres | 10.00R20 16PR |
| Fuel Tank | 130 L aluminum |
| Cab | X9 semi-high, A/C |
| Warranty | 1 year / 100 000 km |
