Beiben NG80 350HP 6×4 9.4m Flatbed Cargo Truck
No.:
Vehicle Type: Cargo Truck
Brand Name: BEIBEN
Person in charge: Aria Dong
Cel: 8617667810120
Whatsapp: 86153364889276
E-mail: sales12@chinatruck.cc
FREE GET QUOTE
Details
Wheel base (mm) | 5950+1450 | |||
Engine | Model | WP10.350E53 | ||
Power, max kw | 350 | |||
Max torque(Nm/rpm) | 1600/1200-1600 | |||
Emission standard | EURO 5 | |||
Fuel tanker capacity L | 300 | |||
Gearbox | Mode | 10JSD160 | ||
Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system | ||
Assistant brake | Engine exhaust brake | |||
Park brake | Potential springs pressing on middle and rear wheels | |||
Frame of vehicle | Fish belly shape, variable width, variable section side beam structure | |||
Front axle (Mercedes Benz Technology) | Double-shoe pneumatic brake, non-driving steering axle | |||
Middle and Rear axle (Mercedes Benz Technology) | Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle | |||
Tyre | 11.00R20 | |||
Electrical system | Battery | 2X12V/135Ah | ||
Generator | 28V-35A | |||
Starter | 5.4Kw/24V | |||
Cab | Short cab, made by full steel material, anticrash performance can be ensured by double hollow chamber structure.Inner A/C | |||
