Cabin

Long and high cabin with A/C, two bed

Major color of cab: Ice white lacquer+ color bar, date red lacquer, dolphin grey

Vehicle Main Dimensions

L*W*H(mm)

6100x2500x3450

Wheel base(mm)

3500

Weight

in KGS

Tare Weight(kg)

5800kg

Trailer Total mass (kg)

18000kg

Driving Speed(km/h)

110

Engine

Brand

Weichai WP10.290E32

Max. output

290hp@2200rpm

Max torque

1160NM@1200-1600rpm

Gear box

Fast  9JS119B   9 speeds 1 reverse

Clutch

Φ430 Diaphragm type, Single dry frictional disc, Hydraulic boosting

Tyre

Tyre

315/80R22.      6+1 Piece

Fuel tank

400L Aluminum Tank

Front axle

Mercedes Benz Technology, 6.5t Double-shoe pneumatic brake, non-driving steering axle

Rear axle

Mercedes Benz Technology, 13t  North Pennines after double reduction axle ratio 5.9 pairs of shoe pneumatic brake, hypoid gear drive axle, four U-bolts

Spring

3/3+3 Strengthened rear spring 22mm, 4-line U-bolt, Strengthened Push Rod, Strengthened Transmission Shaft

Saddle

3.5’’or 2.0’’

Made in China
