Traction type: 8x4

Driving type: LHD

Cabin: HW79 cabin, double sleepers with A/C

Engine brand: Steyr (SINOTRUK)

Engine model: WP10.380E22

Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line

with water cooling, turbo-charging & intercooling

Displacement: 9.726 liters

Max. output: 380hp@2200rpm

Gear box: 10 speeds (HW19710)

Torque: 1800Nm

Clutch:Φ430 Diaphragm type

Steering: ZF8098

Front axle: HF7 7tons

Rear axle: HW1697 strengthened axle (punching-welding axle housing, double reduction driving axle, inter-wheel differential and differential lock)

Tyre : 12.00-20 (rim: 8.5-20) bias tire

Spring: 14,13/12

Fuel consumption (L/ 100km ): 36

Fuel tank capacity (L): 380

Max. speed (km/h): 102

Max. gradeability(%): 28

Kerb. mass: 13420 kg

Total mass: 31000kg

Wheel base (mm): 1800+4600+1350

Front overhang (mm): 1500

Rear overhang (mm): 2734

Rear track (mm): 1830

Approach angle: 16 degree

Departure angle: 14 degree

Dimension (mm): 12000x2496x3633

Body:9280mm*2326mm*600mm

Thickness: floor 3mm side 2mm
