Cabin

Four points suspension Cabin with spring and air shock absorber, Adjustable steering,

Sun cover, A/C, low cabin with single sleeper

Engine

Type: Diesel 4-stroke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling.

Model:

WD615.69

STEYR technology(CNHTC)

Engine power

336hp/247kw

Displacement(L):

9.726 liter (Euro 2 standard)

Max torque:

1350NM@1100-1400rpm

Bore/stoke:

126mm/130mm

Fuel consumption:

188g /kwh

Gear box

CNHTC

Max torque:1900NM

Model:

HW19710

Speed:

10speed, 2 reverse

Axle(front/rear)

Front axle

HF7 STEYR technology front steering axle

Tandem

HC16 double reduction hub reductor driving axle

Clutch

D430 diaphragm type clutch

Brake

Service brake: Dual lines air brake

Parking brake: Spring-Power drum brake

Engine brake: Engine exhaust brake(EVB)

Steering

ZF8098, driver sit at the left hand side

Electric  Equipment

Operating voltage:

24Vnegative grounded

Starter:

24V,5.4KW

Alternator

28V,758W

Battery voltage

12V/135Ah,cigar lighter

Frame

Strengthen steel frame, designed according to tough road condition.

Tyre

10+1 spare tyre with rim

12.00R20

Suspension system: Strengthen heavy duty Leaf spring type

Front/Rear

9/12

Overall dimension(mm): 6800x2496x3718(Length x width x height)

Wheelbase

3225+1350mm

Track:

Front/Rear

2022/1830

Approach/Departure angle

16/70

Front /Rear overhang

1500/725

Max speed

90km/h

Kerb weight:

8800kg
