Maximum theorical pressure on concrete                  MPa

11.3

Rated working pressure                             MPa

42

Pumping frequency                                     min^-1

26

Hopper volume                                          L

550

Filling height                                          mm

1540

Hydraulic circuit

Open

Transfer tube

S valve

Concrete cylinders (diam. × stroke)                  mm

Φ260×2100

Hydraulic oil cooling

air cooling

Concrete slump range                                  cm

12~23

Max. diameter of pumping concrete aggregate            mm

40

Arm and structural form

Model

59X-6RZ

Reach height                                        m

58.1

Slewing radius                                       m

52.9

Reach depth                                         m

41.7

Rotation angle

±270°

Section numbers

6

Arm section length                                     mm

12265/8670/8400/12080/6185/6500

Unfolding angle

90/180/180/240/195/90

Pipeline diameter                                     mm

125

End hose length                                   mm

3000

Minimum unfolding height                        mm

15340

Longitudinal span of stabilizer               mm

9540×13370×10870

Chassis and whole truck

Model

Arocs  4146  E6  8×4

Wheelbase                                               mm

2000+4350+1350

Engine model

OM470LA.6-56

Rated power                            kW/（r/min）

335/1600

Max. torque                            N.m/（r/min）

2200/1100

Overall weight                                         kg

44000

Outline dimension                         mm

14690×2530 ×4000

Others

Lubrication method

Automatic lubrication

Hydraulic tank volume                                 L

201L+338L

Control method

Manual+remote control

Maximum pressure  of water pump                    MPa

7~8

Volume of water box                                      L

400

Concrete pipe cleaning methods

Washing/dry cleaning
