Technical Specifications

Engine & Drivetrain

• Engine Model: Weichai WP6G162E351

• Rated Power: 162 HP (119 kW) @ 2,200 rpm

• Emission Standard: China Stage III (equivalent to EU Stage IIIA)

• Transmission: ZF 4WG170 or equivalent powershift (4F/2R)

• Torque Converter: Single-stage, 3-element with lock-up clutch

Working Performance

• Operating Weight: 16,800 kg

• Bucket Capacity (Rock): 3.0 m³ (standard); AR450 wear-resistant steel

• Max. Dump Height: 3,350 mm

• Max. Breakout Force: 175 kN

• Rated Load Capacity: 5,000 kg

• Travel Speed: 38 km/h (max)

Specialized Desert Configuration

• Tires: 23.5-25 L-4 desert-grade radial tires (extra-deep tread, heat-resistant compound)

• Cooling System: Oversized radiator + oil cooler with automatic reversing fan

• Air Intake: Dual-stage cyclone pre-cleaner + high-efficiency main filter

• Undercarriage: Sealed wheel hubs and corrosion-resistant paint system

Operator Environment

• Cab: Fully enclosed ROPS/FOPS certified cabin

• Climate Control: Optional heavy-duty air conditioning (tested up to 55°C)

• Visibility: Panoramic glass, rear-view camera, LED work lights

• Controls: Ergonomic mechanical pilot levers with low effort

Key Operational Advantages

1. Engineered for the Algerian Desert

✅ Sand & Dust Protection: Triple-filtration air intake system prevents engine wear in Sahara conditions
✅ Thermal Management: Cooling package validated in 50°C+ ambient temperatures
✅ Traction & Floatation: Wide desert tires reduce ground pressure to 98 kPa—ideal for loose sand and soft soil

2. High Productivity in Quarries & Mines

• 3.0m³ rock bucket loads dump trucks in 4–5 cycles

• Reinforced boom and tilt cylinders handle repetitive high-load operations

• Hydraulic quick coupler allows rapid switch to forks, grapples, or coal buckets

3. Reliability & Low Operating Cost

• ZF transmission ensures smooth shifting and long service life

• Centralized grease system reduces daily maintenance time by 40%

• Fuel consumption optimized at 22–26 L/h under standard load

Algeria-Specific Support Package

Warranty & Certification

• Warranty: 24 months on engine, transmission, and hydraulic system

• Certifications: CE, ISO 9001, and full documentation for Algerian customs clearance

• Manuals: Available in Arabic, French, and English

Local Service Readiness

• Spare parts stocked in Algiers, Oran, and Hassi Messaoud via partner network

• On-site commissioning and operator training included

• WhatsApp technical support in French/Arabic with <2-hour response time

Delivery Timeline

1. Inquiry: Message “XC958 DESERT” to William Du on WhatsApp (+86 186 6977 8647)

2. Configuration Review: Receive Algeria-tuned spec sheet within 24 hours

3. Field Test Video: Watch machine operating in simulated desert conditions

4. Shipment: Departure from Qingdao/Tianjin within 30 days; arrival in Algeria in ~22–28 days

Current Availability: 8 units with September 2025 build dates—ready for immediate reservation

Contact: William Du
Verified Supplier For: Major mining & infrastructure projects in Algeria (including Sonatrach, ENTP, and private quarry operators)
WhatsApp/WeChat: +86 186 6977 8647
