Model name

SINOTRUK SITRAK G7 TRACTOR TRUCK

Driving type

Left hand drive

Traction type

6X4

Scope of application

Transportation of industrial and daily necessities

Color

Optional

Weights

Gross Vehicle Weight(kg)

Approx.9800

Gross Combination Weight(kg)

Approx.55000

Dimensions

Wheelbase(mm)

3200+1400mm

Overall dimension(mm)

Approx. 6895×2496×3980

Engine

Engine model

MC13.48-61, 480HP

Emission standard

Euro 5

Engine type

4 stroke water-cooled, inter-cooling

No. of cylinders

straight-6 cylinders

Displacement(L)

12.419L / Diesel

Max. output (kw)

353kW

Fuel Tanker

860L+240L dual fuel tank

Drive Line

Gearbox

HW25716XAL

16 speeds, 16 forwards, 2 reverse gear,

AMT gearbox

Steering

Power steering, Bosch steering gear

Brake

Front axle disc brakes, dual rear axle drum brakes

Cab

Cabin

G7-G cab Elite version, High roof, 3passengers allowed double sleeper, airbag seats

Can be tipped forwardly, with inner A/C

Standard configuration

Air container,

Equipped with air deflector and side air deflector

Axle

Front axle

VPD71DS 7.0T- Disc Brake

Rear axle

12T MCJ12BGY self-adjusting arm double rear axle with inter-wheel & inter-axle differential locks

Double reduction pneumatic brake

Speed ratio

2.85

Tire specification

Tire specification

Front aluminum alloy wheels + rear lightweight wheels

12R22.5 (Low rolling resistance/international brand)

6 tires+1 spare part

Parameter

Maximum speed (km/h)

89

Max. Gradeability

35(%)

Torque (Nm)

2300

Suspension

Front few leaf springs (2); Rear air suspension

Frame(mm)

TGA technology frame - version B

Saddle

90# JOST saddle

Bumper

Low bumper (non-metallic)

Fender

Integral fender

Power System

180AH battery

Safety devices

ABS(4S/4M)+ESC

Imaging system

Four directional camera

exhaust system

Standard version exhaust system
