Sinotruk TX-F 6×4 371 HP Euro II Angola-Congo-Kinshasa 20 m³ Construction Dump Truck for Sale
Key Features
20 m³ square dump body, 4 mm floor / 3 mm sides, front telescopic lift, 45° tipping angle.
371 HP WD615.47 Euro II engine, 1460 N·m torque, HW19710 10-speed + HW50 direct PTO.
6×4 drive, 3825+1350 mm wheelbase, 5.451 ratio MCX16ZG manual rear axles.
Reinforced 8+8/300 mm double-layer frame, 11/12 leaf springs for 30 t GVW.
TX-F sleeper cab, 300 L fuel tank, dust-proof intake, full-metal bumper, no ABS for cost-effective markets.
Specifications
复制
| Item | Specification |
|---|---|
| Model | Sinotruk TX-F 6×4 Dump |
| Engine | WD615.47, 371 HP Euro II |
| Displacement | 9.7 L |
| Gearbox | HW19710 10-speed + HW50 PTO |
| Drive | 6×4 |
| Wheelbase | 3 825 + 1 350 mm |
| Dump Body | 20 m³ (5 600 × 2 300 × 1 500 mm) |
| GVW | 30 000 kg |
| Curb Weight | 12 800 kg |
| Rated Payload | 17 200 kg |
| Front Axle | VGD95, 9.5 t drum |
| Rear Axle | MCX16ZG 16 t ×2, 5.451 ratio |
| Frame | 8+8/300 mm double-layer |
| Suspension | 11/12 leaf springs |
| Tires | 12.00R20 mixed 18PR |
| Fuel Tank | 300 L aluminum |
| Cab | TX-F sleeper, air seat |
| Max Speed | 80 km/h |
| Certification | ISO9000, CCC, Angola/Congo/Kinshasa |
| Warranty | 1 year / 100 000 km |
