Sinotruk TX-F 6×4 371-430 HP Euro II D.R. Congo Mining Dump Truck 20-25 m³ for Sale
No.:
Vehicle Type: Dump Truck
Brand Name: SINOTRUK
Person in charge: Shawn Ma
Cel: 0086 18254796503
Whatsapp: 8618254796503
E-mail: sales20@chinatruck.cc
FREE GET QUOTE
Details
Sinotruk TX-F 6×4 371-430 HP Euro II D.R. Congo Mining Dump Truck 20-25 m³ for Sale
Key Features
20-25 m³ rectangular dump body: 5600-7800 × 2300 × 1500-1700 mm, 10 mm floor / 8 mm sides in T700 high-strength steel.
371 HP WD615.47 or 400-430 HP WP12 Euro II engines, 1460-2060 N·m torque, HW19710 10-speed + HW50 direct PTO.
6×4 drive, 3825+1350 mm wheelbase, 5.26-5.451 ratio MCP16ZG rear axles for heavy-load climbing.
Reinforced 8+8/300 mm double-layer or 8+8+8/300 mm triple frame, 11/12 leaf springs for 40 t GVW.
Mine-spec safety: French/Portuguese dashboard, cab roof warning lights, fire extinguisher, reversing buzzer, headlight & bumper guards, battery & fuel anti-theft devices.
Hydraulics: Hyva 157-179 front telescopic lift, Φ20 mining-grade chain locks, manual rear door locks with anti-jump teeth.
Specifications (representative 430 HP 25 m³ unit)
| Item | Specification |
|---|---|
| Model | Sinotruk TX-F 6×4 Mining Dump |
| Engine | WP12S430E201, 430 HP Euro II |
| Displacement | 11.6 L |
| Gearbox | HW19710 10-speed + HW50 PTO |
| Drive | 6×4 |
| Wheelbase | 3 825 + 1 350 mm |
| Dump Body | 25 m³ (6 800 × 2 300 × 1 550 mm) |
| Material | T700 high-strength steel (10 mm floor / 8 mm sides) |
| GVW | 40 000 kg |
| Curb Weight | 15 500 kg |
| Payload | 24 500 kg |
| Front Axle | VGD95, 9.5 t drum |
| Rear Axle | MCP16ZG 16 t ×2, 5.26 ratio |
| Frame | 8+8/300 mm double-layer |
| Suspension | 11/12 leaf springs |
| Tires | 12.00R20 mixed 18PR |
| Fuel Tank | 400 L aluminum, anti-theft |
| Cab | TX-F sleeper, air seat, roof lights |
| Hydraulics | Hyva 179 front lift |
| Max Speed | 80 km/h (speed-limiter) |
| Certification | ISO9000, CCC, Angola/Congo/Kinshasa |
| Warranty | 1 year / 100 000 km |
