Sinotruk HOWO 24m 28m 30m 33m Aerial Work Lifting Truck High Altitude Operation Truck
No.:
Vehicle Type: Aerial Work Truck
Brand Name: SINOTRUK
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
SINOTRUK HOWO 4×2 104 kW Euro III 28-33 m Telescopic Boom Aerial Work Platform Truck for Sale
Key Features
28–33 m working height, 14+ m outreach, 200 kg stainless-steel basket (1200×700×1150 mm).
Four-section hexagonal synchronous telescopic boom, external cylinders, chain drive—easy service.
Front V + rear H hydraulic outriggers, individual control, auto-level sensor for stability on slopes.
360° continuous hydraulic rotation, dual interlocked control stations (basket + turntable) + manual emergency.
Load-sensitive proportional valves, balance valves, automatic limiting, audible danger alarm.
HOWO 4×2 chassis, 104 kW YN4102QBZL Euro III, 6-speed manual, A/C cab, 120 L fuel tank.
Specifications
复制
| Item | Specification |
|---|---|
| Model | SINOTRUCK HOWO 28-33 m Aerial Work Truck |
| Chassis | HOWO 4×2 LHD |
| Engine | YN4102QBZL, 104 kW / 3800 ml, Euro III |
| Gearbox | 6F + 1R manual |
| Wheelbase | 3 360 mm |
| Overall Size | 5 900 × 2 050 × 2 900 mm |
| GVW | 4 495 kg |
| Curb Weight | 4 365 kg |
| Max Speed | 95 km/h |
| Tyres | 7.50R16 (6+1) |
| Boom | 4-section hexagonal telescopic |
| Working Height | 28 – 33 m (customer option) |
| Outreach | 14 m+ |
| Basket Load | 200 kg |
| Rotation | 360° continuous |
| Outriggers | Front V, rear H, individual |
| Control | Electric-hydraulic + manual emergency |
| Certification | ISO9001, 3C |
| Warranty | 1 year / 100 000 km |
| Production | 15-20 days |
Contact us for pricing and configuration options!
