SINOTRUK Fire Truck: High-Performance Firefighting Solutions
No.:
Vehicle Type: Fire Truck
Brand Name: SINOTRUK
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
Product Description: SINOTRUK Fire Truck: High-Performance Firefighting Solutions
The SINOTRUK fire truck is designed for high-performance firefighting, suitable for fire departments, hazardous materials, and special industries. This robust vehicle features powerful pumps, long-range nozzles, and versatile tank designs, ensuring reliable performance in demanding conditions.
| SPECIFICATIONS FOR FIRE TRUCK | |||
| Name | Fire-extinguisher water tanker | ||
| Model | KWZ5190GXFPM80H | ||
| Chassis Type | ZZ1167M4617C | ||
| Driving Type | 4×2 | ||
| Wheel Base (Mm) | 4600 | ||
| Seating capacity | 6 | ||
| ENGINE | |||
| Type | WD615.92C | ||
| Power(KW) | 198 | ||
| Torsion | 1190N·m(1200-1500r/min) | ||
| DIMENSION PARAMETER | |||
| Dimension (Mm)L×W×H | 8570×2500×3570 | ||
| Overhang(Mm) | Front | 1500mm | |
| Rear | 2310mm | ||
| Approach Angle/Departure Angle | 16°/13° | ||
| min ground clearance | 260mm | ||
| FUNCTION PARAMETER | |||
| Turning Diameter | 17m | ||
| Maximum Speed(Km/H) | ≤ 90km/h | ||
| LOAD CAPACITY | |||
| Maximum Authorized Total Mass | 10950kg | ||
| Water | 8000kg | ||
| FIRE-FIGHTING EQUIPMENT | |||
| Fire Pump | flow | 60or30L/S | |
| pressure | 1.0or2.0Mpa | ||
| Primer Pump | depth | ≥ 7m | |
| time | ≤ 50s | ||
| Fire Monitor | location | truck roof in central | |
| flow(l/s) | 50 | ||
| pressure(mpa) | ≤1.0 | ||
| flow | 50L/S | ||
| range(m) | ≥70 | ||
| rotation angle | ≥360 | ||
| angle of altitude | ≥+80° | ||
| angle of depression | ≤-15° | ||
Core Application Scenarios
| Item | Details |
|---|---|
| Target Users | Fire Departments, Flammable and Explosive Enterprises, Hazardous Chemicals and Pharmaceutical Industries |
| Fire Types | Class A Fires (Solid Material Fires), Class B Fires (Liquid/Melting Material Fires) |
Chassis and Power Configuration
| Item | Details |
|---|---|
| Chassis Brand | SINOTRUK |
| Drive Types | 4x2, 4x4, 6x4, 8x4 (Adapted to Various Road Conditions) |
| Power Take-Off Models | HW80QZ/100Q (Matched for Efficient Power Output) |
| Fire Pump Flow Rate | 20-170 L/s (Covers Various Firefighting Intensity Needs) |
Firefighting Performance and Medium
| Item | Details |
|---|---|
| Fire Nozzle Range | 50-95 meters (Long-Distance Precision Firefighting) |
| Proportioning Mixer | PH48/64/B-FORM-100 (Supports Foam Mixing for Firefighting) |
| Firefighting Medium | Water, Class B Foam Liquid (High Compatibility) |
Tank Design and Capacity
| Item | Details |
|---|---|
| Material Options | High-Quality Carbon Steel, Stainless Steel 304/316 (Corrosion-Resistant, High Strength) |
| Capacity Range | 200-24000 kg (Full Series Available, Meets Various Scale Needs) |
| Sub-Chassis Structure | Protects the Main Chassis, Extends Chassis Life |
Operation and Maintenance Advantages
| Item | Details |
|---|---|
| Convenience | Simple Operation, Easy Maintenance (Lowers Usage Threshold) |
| Export Compliance | Meets International Export Standards (Expands Overseas Markets) |
Multi-Functional Expansion
| Item | Details |
|---|---|
| Optional Water Sprinkling System | Dual-Purpose for Road Greening and Dust Suppression (Multi-Use Vehicle) |
Cost-Effectiveness
| Item | Details |
|---|---|
| Low Operating Costs | Conventional Structural Design Reduces Maintenance Costs |
| Easy Maintenance | Standardized Components, Minimizes Downtime |
Core Application Scenarios
Target Users:
Fire Departments
Flammable and Explosive Enterprises
Hazardous Chemicals and Pharmaceutical Industries
Fire Types:
Class A Fires (Solid Material Fires)
Class B Fires (Liquid/Melting Material Fires)
Chassis and Power Configuration
Chassis Brand: SINOTRUK
Drive Types: 4x2, 4x4, 6x4, 8x4 (Adapted to Various Road Conditions)
Power Take-Off Models: HW80QZ/100Q (Matched for Efficient Power Output)
Fire Pump Flow Rate: 20-170 L/s (Covers Various Firefighting Intensity Needs)
Firefighting Performance and Medium
Fire Nozzle Range: 50-95 meters (Long-Distance Precision Firefighting)
Proportioning Mixer: PH48/64/B-FORM-100 (Supports Foam Mixing for Firefighting)
Firefighting Medium: Water, Class B Foam Liquid (High Compatibility)
Tank Design and Capacity
Material Options: High-Quality Carbon Steel, Stainless Steel 304/316 (Corrosion-Resistant, High Strength)
Capacity Range: 200-24000 kg (Full Series Available, Meets Various Scale Needs)
Sub-Chassis Structure: Protects the Main Chassis, Extends Chassis Life
Operation and Maintenance Advantages
Convenience: Simple Operation, Easy Maintenance (Lowers Usage Threshold)
Export Compliance: Meets International Export Standards (Expands Overseas Markets)
Multi-Functional Expansion
Optional Water Sprinkling System: Dual-Purpose for Road Greening and Dust Suppression (Multi-Use Vehicle)
Cost-Effectiveness
Low Operating Costs: Conventional Structural Design Reduces Maintenance Costs
Easy Maintenance: Standardized Components, Minimizes Downtime
Notes
Safety Design: Sub-chassis structure prevents damage to the main chassis during firefighting operations, suitable for high-frequency use.
Material Choice: Stainless steel tanks are ideal for corrosive environments (e.g., chemical areas), while carbon steel offers higher cost-effectiveness.
Flexible Adaptation: Wide range of drive types and capacities, customizable to meet the needs of enterprises or fire departments.
Environmental Expansion: Optional water sprinkling system meets urban environmental needs, enhancing equipment utilization.
