SHACMAN SAGMOTO X3s 6×4 385 HP Cummins Euro III 10-Wheel 20-Ton Dump Tipper Truck for Sudan

No.:

Vehicle Type: Dump Truck

Brand Name: SHACMAN SAGMOTO

Shacman Trucks

I want to inquire

Person in charge: William Du

Cel: 8618669778647

FREE GET QUOTE

SHACMAN SAGMOTO X3s 6×4 385 HP Cummins Euro III 20-Ton Dump Tipper Truck for Sudan

Key Features

Engine: 385 HP / 1 830 N·m Cummins ISME 385-30, water-cooled, turbocharged, Euro III.
Gearbox: Manual Fast 810JSD180 10-speed cast-iron, precise shifting for heavy loads.
Payload: 20 tons on 16-ton two-stage rear axle (5.92 ratio).
Chassis: 6×4 drive, 3775+1400 mm wheelbase, 850×300/8+7 mm high-strength frame.
Suspension: 10/12 leaf springs (four main + four auxiliary) for stability on rough terrain.
Fuel Tank: 400 L aluminum for long-distance operations.
Cab: X3s medium-long half-high roof, airbag driver seat, A/C, 5" LCD cluster, Bluetooth.
Extras: 180 Ah maintenance-free battery, oil-bath air filter, headlight/taillight grilles, 50-ton jack, optional desert wind-proof sump guard.

Specifications

Project	description
Model	SX3253M3M39J3840
Driving position	left standard rudder
Driving type	6*4
Engine	Cummins ISME 385 30
Effluent standard	Europe 3
Transmission	Fast 810JSD180(cast iron)-QH50
Vehicle speed ratio	16t/ two-stage/5.92
Frame (mm)	850×300 /8+7
Wheel base(mm)	3775+1400
Front axle	9.5t
Suspension	10/12 (four main films+four horseback riding)
Fuel tank	400L Aluminum fuel tank
Wheels and tires	12.00R20/18PR
Other configurations	1. Cab: X3s medium-long and half-high roof, airbag shock-absorbing main seat, fixed auxiliary seat, four-point mechanical mount, halogen headlights, multi-function steering wheel, lever rearview mirror, automatic constant temperature air conditioner, electric window, 5-inch LCD screen combination instrument, Bluetooth player (with 5-inch screen)., manual turnover, central locking (1 central key +2 mechanical keys), M3000S metal bumper (bumper can be the same color as the cab or black bumper), cast outrigger/central towing hook, three-step stepping and sunshade; 2. Chassis: 180Ah maintenance-free battery, iron gas cylinder, spare wheel rack with spare wheel, oil-bath air filter, headlight and taillight protection grille, 50t jack, water tank protection grille+oil pan protection grille (optional in desert area: windproof oil pan protection grille). 3. Logo: with non-luminous SQ logo, SAGMOTO logo, English or Chinese and Englis
