Size (mm)

8700 x 2550 x 3500

Box Size (mm)

5600 x 2300 x 1400 , 8mm at the bottom, 6mm at both sides

Lifting system

Middle-lift

Tires

12R22.5, 10+1pcs, rim trim cover

Wheelbase

3775+1400mm

Axle

MAN9.5T front axle，MAN16T rear axle, speed ratio:5.92

Engine

Model

WP10.340E22, Euro II, Diesel

Engine power

250KW (340HP) @ 2200 tr / min

Max torque

1250 N.m @ 1400-1600 tr / min

Air intake type

turbo-charge and inter-cool

Alignment of cylinders

6 cylinders in line

Minimum fuel consumption

≤ 196/ kW .h

Fuel injection type

Direct injection

Gearbox

RTD11509C (iron shell) gearbox with QH50 power take-off, 10 forward speeds + 2 reverse speeds

Fuel tank

380L Steel fuel tank

Suspension

Multiple front and rear springs, four main plates + four riding bolts

Main beam

Double-layer frame 850×300（8+7）

Other

F3000 medium-long flat-top cab, hydraulic main seat, four-point hydraulic suspension, rearview mirror, hot zone air conditioner, electric window opener, manual flip of the cab, metal bumper-light guard net, three-level boarding pedal,

Oil bath air filter, ordinary exhaust, oil pan protective grille, imported clutch, taillight protective grille, 165Ah maintenance-free battery, elastic headrest, manual sunroof, telescopic shaft control,

Six-channel ABS, front lower protection, driving recorder, cruise control system, speed limit 90km/h, seat belt not fastened reminder, reflective vest, SHACMAN logo, full English logo, special signage
