SAIC IVECO Hongyan GENLYON C6 Overloaded version 8x4 420HP dump truck
No.: cynthia11
Vehicle Type: Dump Truck
Brand Name: SAIC-IVECO HONGYAN
Person in charge: Cynthia Sun
Cel: 8617669717525
Whatsapp: 8613396363431
E-mail: sales2@chinatruck.cc
FREE GET QUOTE
Details
| Model | CQ3317HD10286 |
| Drive type | 8X4 |
| Wheelbase | 2000+2500+1400mm |
| Engine | SC10E420Q6 |
| Gearbox | 12JSD200TA-B |
| Rear axle speed ratio | 5.214 |
| Body dimensions | 9385x2550x3460mm |
| Front wheelbase | 2060/2060mm |
| Rear wheelbase | 1858/1858mm |
| Approach angle | 16 |
| Departure angle | 24 |
Standard configuration | Heng long steering gear, intercooler protection frame, 165Ah battery, metal front bumper, electronic fuel pump, optional: high roof long/flat roof short cab, front stabilizer bar, rear stabilizer bar, ZF steering gear, driver's luxury air seat/high-end heated seat/high-end ventilated heated seat, cab electric overturning, plastic bumper, oil bath air filter, 350L/600L/(450+150) L fuel tank, Internet version, harness anti-corrosion, 180Ah maintenance free battery |
| Engine model | SC10E420Q6 |
| No.of cylinders | 6 |
| Displacement | 10.4L |
| Horsepower | 420HP |
| Max. torque | 2000N·m |
| Upbody size | 6500X2350X1500mm |
| Cab | Flat top length |
| Gearbox model | 12JSD200TA-B |
| Shift mode | Manual |
| Fuel tank | 300L |
| Front axle | 7.5T |
| Rear axle | HY300H |
| Tyre | 12.00R20 18PR |
