SAGMOTO I9 4×2 140 HP Euro II Standard-Load Electric Cargo Truck 5.6 m Van for Sale
No.:
Vehicle Type: Light Cargo Truck
Brand Name: SHACMAN SAGMOTO
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
SAGMOTO I9 4×2 140 HP Euro II Standard-Load Electric Cargo Truck 5.6 m Van for Sale
Key Features
Engine: Cummins YC4D140-33, 140 HP Euro II, 6-cyl, >8 L, 2 000–2 500 N·m peak torque.
Gearbox: Manual FAST 8JS85TF-C 5-speed + QD40J PTO for precise load control.
Payload: 8 t (standard) – 12 t (max) GVW, 6 t rear axle (5.286 ratio).
Cargo Options:
– 5.6 m × 2.1 m × 2.1 m van (4150×2100×2100 mm) or stake body (3550×2100×400 mm).
– 18 m 5-section telescopic aerial boom (optional) with 200 kg basket for telecom, signboard & lighting maintenance.Chassis: 850×250/7+4 mm frame, 3 600 mm wheelbase, 2.5 t front axle, 9/11+8 leaf springs.
Cabin: X9 extended half-high, A/C, 5-inch LCD cluster, 10-inch multimedia screen, electric windows & mirrors.
Fuel & Range: 130 L aluminum tank, 300 km range, dual-circuit air brakes + engine exhaust brake.
Specifications
| Item | Specification |
|---|---|
| Model | SX5123ZGKE2Y14J3611 |
| Drive | 4×2 (LHD or RHD) |
| Engine | Cummins YC4D140-33 140 HP Euro II |
| Gearbox | Manual FAST 8JS85TF-C 5-speed |
| Payload | 8–12 t GVW |
| Cargo Body | 5 600 × 2 100 × 2 100 mm van or 3 550 × 2 100 × 400 mm stake |
| Wheelbase | 3 600 mm |
| Tyres | 8.25R20 16PR (6+1) |
| Fuel Tank | 130 L aluminum |
| Cabin | X9 half-high, A/C |
| Max Speed | 90 km/h |
| Aerial Platform (opt.) | 18 m height, 200 kg basket |
| Certification | ISO9001, 3C |
| Warranty | 1 year / 100 000 km |
Contact us for pricing and customization!
