New Model SINOTRUK Sitrak C7H 8x4 480HP 40T DUMP TRUCK
No.: Cynthia82
Vehicle Type: Sitrak Dump Truck
Brand Name: SINOTRUK
Person in charge: Cynthia Sun
Cel: 8617669717525
Whatsapp: 8613396363431
E-mail: sales2@chinatruck.cc
FREE GET QUOTE
Details
SITRAK 8X4 Dump Truck Application:
Purpose: Ideal for demanding urban environments and construction sites ;
Fuel Tank: 400L capacity for extended operational hours ;
Tyres: 13R22.5 block pattern tyres for stability on diverse terrains ;
Bumper: High full-metal bumper for added protection ;
ABS System: Advanced ABS (4S/4M) system for enhanced safety ;
Applications: Suitable for city dumping, large-scale material transport, and construction projects .
The Sitrak ZZ2316N256HF1 combines power, efficiency, and safety features, making it a reliable choice for various heavy-duty tasks in urban and construction settings.
Specification
| Model name | SITRAK C7H DUMP TRUCK |
| Model | ZZ2316N256HF1 |
| Driving type | Left hand drive |
| Traction type | 8×4 |
| Color | optional |
| Gross Vehicle Weight(kg) | Approx.15500 |
| Gross Combination Weight (kg) | Approx.60000 |
| Wheelbase(mm) | 3775+1400 |
| Engine model | MC13.54-61 |
| Emission standard | Euro 5 |
| Engine type | 4 stroke water-cooled, inter-cooling |
| No. of cylinders | straight-6 cylinders |
| Displacement(L) | 12.42 / Diesel |
| Max. output (kw) | 400 |
| Fuel Tanker（L） | 800 aluminum fuel tank |
| Gearbox | HW25712XSJHW50 flange power take-off 12 speeds, 12 forwards, 2 reverse gear, AMT |
| Steering | Power steering |
| Brake | Air brake, engine exhaust brake |
| Cabin | length flat top cab, double sleeper, with A/C; Can be tipped forwardly, with inner A/C and one sleeper bed |
| Standard configuration | Air container |
| Front axle | 6500/7000kg |
| Rear axle | MCP23ZG |
| Tyre | 12.00R22.5 standard tire,12 tires+1 spare part |
| Economic speed/maximum speed (km/h) | 40～55/75 |
| Max. Gradeability | 35(%) |
| Rear overhang(mm) | 1450 |
| Suspension | Leaf spring, 11/11/12 |
| Color | Customized |
| Body dimension(mm) | 8800x2380x1580 |
| Body volume(m3) | 33.1 |
| Material | Carbon steel plates |
| Lifting method | Front hydraulic lifting system |
