Technical Specifications

Engine & Drivetrain

• Engine Model: YTO LR4M5U23/125

• Rated Power: 125 HP (92 kW) @ 2,200 rpm

• Transmission: ZF 4WG160 or equivalent powershift (4F/2R)

• Torque Converter: Single-stage, 3-element

• Drive System: Full hydraulic steering with load-sensing priority valve

Working Performance

• Operating Weight: 10,200 kg

• Bucket Capacity (Rock): 1.8 m³ (standard); 2.0 m³ (general purpose optional)

• Max. Dump Height: 3,100 mm

• Max. Breakout Force: 105 kN

• Rated Load Capacity: 3,000 kg

• Travel Speed: 38 km/h (max)

Hydraulic & Control System

• Main Pump: Gear pump, 35 L/min flow

• Working Pressure: 18 MPa

• Steering System: Full hydraulic, articulated frame

• Control Levers: Mechanical pilot control with ergonomic layout

Operator Environment

• Cab: ROPS/FOPS certified, sound-insulated

• Seat: Adjustable suspension seat

• Visibility: Panoramic windshield with rear-view mirror

• Optional: Air conditioning, reversing camera, LED work lights

Key Operational Advantages

1. Built for Algerian Conditions

✅ Dust Protection: Dual-stage air filter and sealed electrical connectors for Sahara-region operations
✅ Heat Resistance: Enhanced cooling system tested up to 50°C ambient temperature
✅ Rock Handling: High-strength bucket with wear-resistant AR400 steel plates and reinforced side cutters

2. Efficiency & Versatility

• Hydraulic quick coupler enables fast switching between rock bucket, general bucket, pallet fork, or snow blade

• Short wheelbase (2,750 mm) ensures excellent maneuverability in tight quarry spaces

• Low fuel consumption (~14–16 L/h under standard load) due to optimized engine-transmission matching

3. Safety & Reliability

• Dual-circuit full hydraulic braking system with automatic parking brake

• Emergency steering backup in case of engine stall

• Centralized lubrication points for easy daily maintenance

Support & Delivery for Algeria

Warranty & Certification

• Comprehensive Warranty: 18 months on engine, transmission, and hydraulic system

• Certifications: CE, ISO 9001, and Algerian customs-compliant documentation

• Language Support: Operation manuals in Arabic, French, and English

Algeria-Specific Service Package

• Spare parts pre-positioned in Oran and Algiers via local partners

• On-site commissioning and operator training available

• WhatsApp-based technical support in French/Arabic

Delivery Timeline

1. Inquiry: Message “LW300KN ALGERIA” to William Du on WhatsApp (+86 186 6977 8647)

2. Configuration: Receive Algeria-tailored spec sheet within 24 hours

3. Pre-Shipment Test: Video of machine loading rocks at factory test yard

4. Shipment: Departure from Tianjin Port within 30 days; arrival in Algiers/Oran in ~25 days

Current Stock: 10 units with August 2025 build dates ready for immediate allocation
