Kailai Hubei Tri-Ring 4×2 Hook-Arm Garbage Truck YZZ5040ZXXST6 - 118kW Euro III-VI, 3.62m Bin, ≤60s Swap, ABS+A/C, Global Export
No.:
Vehicle Type: Garbage Truck
Brand Name: KAILAI
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
Kailai Hubei Tri-Ring 4×2 Hook-Arm Garbage Truck YZZ5040ZXXST6 - 118kW Euro III-VI, 3.62m Bin, ≤60s Swap, ABS+A/C, Global Export
Key Features
3.62m sealed bin: swap in ≤60s, lift ≤60s, self-unload ≤25s up & down, metal rolling wheels
Euro III-VI power: Yunnei 118kW (2.5L), 8-speed manual, F1 flat-roof cab, Bluetooth, laminated glass, electric doors/windows, central locking
Light-duty chassis: 192×65(6+4)mm frame, 5/7+5 leaf springs, 6.33 ratio, 7.00R16-8 tyres, drum brakes with ABS
Full-hydraulic hook: double-acting cylinder, multi-way valve, manual control, self-unloading
Global specs: 24V dual 100Ah batteries, spring parking brake, triangular warning sign, tool kit, A/C
Kailai 12-month warranty, CCC/ISO9001, fast 15-day production, DDP sea/air worldwide
Specifications Summary
复制
| Item | Specification |
|---|---|
| Model | YZZ5040ZXXST6 |
| Drive | 4×2, LHD/RHD optional |
| GVW | 4,495kg |
| Curb weight | 3,900kg |
| Dimensions | 5,620×2,100×2,300mm |
| Wheelbase | 3,360mm |
| Engine | 118kW Euro III-VI (Yunnei 2.5L) |
| Gearbox | 8-speed manual |
| Front axle | 2,200kg drum |
| Rear axle | 6,000kg drum, 6.33 ratio |
| Hook bin | 3,620mm length, ≤60s lift/lower |
| Hydraulic system | Double-acting cylinder, multi-way valve |
| Electrical | 24V, dual 100Ah batteries |
| Warranty | 12 months |
Usage & Safety
Pre-start check oil, air, hydraulic levels; confirm bin is properly locked before driving.
Never exceed 3.62m bin length; use balance valve to prevent sudden drop during unloading.
Clean hydraulic filter every 500 cycles; grease hook rollers weekly.
Contact us for pricing and configuration options！
Contact: William
Phone/WhatsApp/WeChat: +86 18669778647
Email: Sales22@chinatruck.cc
