ISUZU 4×2 98 HP Euro V 28-30 m Telescopic Boom Aerial Work Platform Truck for Sale
No.:
Vehicle Type: Aerial Work Truck
Brand Name: ISUZU
Person in charge: Shawn Ma
Cel: 0086 18254796503
Whatsapp: 8618254796503
E-mail: sales20@chinatruck.cc
FREE GET QUOTE
Details
ISUZU 4×2 98 HP Euro V 28-30 m Telescopic Boom Aerial Work Platform Truck for Sale
Key Features
28-30 m max working height, 19 m outreach (70 kg) / 11 m (200 kg), 200 kg basket rated load.
Five-section pentagonal synchronous telescopic boom, high-strength steel, compact retraction.
±360° continuous hydraulic rotation, ±360° basket swivel for precise positioning.
Front V + rear H hydraulic outriggers, individual adjustment, auto-level sensor.
Triple control: wireless remote, platform joystick, manual emergency levers.
CAN-bus diagnostics, 7-inch real-time display, overload & tilt alarms.
ISUZU 4KH1CN5LS 98 HP Euro V diesel, 5-speed gearbox, 120 L fuel tank.
Stainless-steel super-large bucket (1600×710×1200 mm), non-slip floor, LED work lights.
Specifications
复制
| Item | Specification |
|---|---|
| Model | ISUZU 28-30 m Aerial Platform |
| Chassis | ISUZU 4×2 LHD |
| Engine | 4KH1CN5LS, 98 HP Euro V |
| Displacement | 2.999 L |
| Wheelbase | 3 360 mm |
| Overall Size | 5 998 × 2 000 × 3 150 mm |
| GVW | 4 495 kg |
| Curb Weight | 2 130 kg |
| Max Speed | 98 km/h |
| Tyres | 700R16 (6+1) |
| Boom | 5-section telescopic |
| Working Height | 28-30 m |
| Outreach | 19 m (70 kg) / 11 m (200 kg) |
| Basket Load | 200 kg |
| Rotation | ±360° continuous |
| Outriggers | Front V, rear H, individual |
| Control | Wireless + platform + manual |
| Certification | ISO9001, 3C |
| Warranty | 12 months |
| Production | 15-20 days |
Contact us for pricing and customization options!
Contact: william
Phone/WhatsApp/Wechat: +86 18669778647
Email: Sales22@chinatruck.cc
