Foton Electric Bus | 56-Seater Zero-Emission Transit Bus | 200km Range
No.:
Vehicle Type: Intercity Bus
Brand Name: FOTON
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
Technical Specifications
Category | Specification |
|---|---|
Dimensions (L×W×H) | 12000 × 2550 × 3220 mm |
Wheelbase | 6000 mm |
Gross Vehicle Weight | 18000 kg |
Seating Capacity | 56 passengers (32 seated + 24 standing) |
Battery Capacity | 350 kWh (LiFePO4) |
Range | 200 km (real-world urban conditions) |
Motor Power | 240 kW (peak) / 150 kW (continuous) |
Max Speed | 70 km/h |
Charging Time | 2.5 hrs (DC fast charging, 150 kW) |
Suspension | Full air suspension |
Core Technologies
•
Battery System:
•
LiFePO4 chemistry (4,000+ cycles)
•
IP68 waterproof/dustproof protection
•
e-AIR thermal management (±1°C control)
•
Powertrain:
•
Permanent magnet synchronous motor
•
Regenerative braking (20% energy recovery)
•
Safety & Comfort:
•
ABS + EBD + ESC braking system
•
Electric A/C with PM2.5 filtration
•
Low-floor design (340mm entry height)
Operational Advantages
•
Ultra-Low Operating Costs:
•
30% lower TCO vs diesel buses
•
Energy consumption: ≤100 kWh/100km
•
Smart Fleet Management:
•
Real-time battery monitoring (SOC/SOH)
•
Remote diagnostics via 4G/5G
•
OTA firmware updates
•
Durability:
•
High-strength steel frame
•
Corrosion-resistant aluminum panels
Certifications
•
China GB/T 34013-2017
•
UNECE R100/R136
•
CE/UKCA (EU/UK markets)
Applications
•
City public transit routes
•
Airport terminal shuttles
•
School/university transport
•
Tourist hop-on/hop-off services
After-Sales Support
•
Warranty: 8-year battery / 5-year vehicle
•
Global Service: 200+ certified centers
•
24/7 Support: Technical hotline
