Foton 3 m³ Hook-Lift Arm Garbage Truck – Compact Roll-Off Waste Collector for City Streets for Sale
Key Features
• Compact & Agile – 4.8 m overall length, 2.8 m wheelbase, perfect for narrow alleys and gated communities
• 3 m³ Roll-Off Bin – 2 000 mm entrance width, trapezoid / boat / square shapes, above/under-ground options
• High Hook Capacity – 3–4 t rated lift, twin telescopic cylinders, 19.6 MPa max pressure
• Rapid Cycle – ≤30 s loading, ≤45 s discharging, ≥1:4 compression ratio
• Stable Operation – Double hydraulic rear landing legs, automatic levelling valve
• Multi-Chassis Options – Dongfeng, Isuzu, Hino, Sinotruk, JAC, FAW, Foton 4×2 Euro-3/4/5
• One-Operator – Cab & rear manual valves + optional wireless remote
Specifications
| Parameter | Value |
|---|---|
| Drive Type | 4×2, LHD |
| Overall Dimension (L×W×H) | 4 835 × 1 870 × 2 120 mm |
| Tank Cubage | 3 m³ |
| Entrance Width | 2 000 mm |
| Hook Capacity | 3–4 t |
| Max Loading Mass | 6 000 kg |
| Gross Vehicle Weight | 4 495 kg |
| Curb Weight | 2 150 kg |
| Wheelbase | 2 800 mm |
| Front / Rear Axle Load | 1 800 kg / 3 500 kg |
| Engine Model | ISD245 50 (optional) |
| Emission Standard | Euro 3 / 4 / 5 |
| Fuel Type | Diesel |
| Max Driving Speed | 90 km/h |
| Compress Ratio | ≥1 : 4 |
| Max Hydraulic Pressure | 19.6 MPa |
| Loading Cycle Time | ≤30 s |
| Discharging Time | ≤45 s |
| Control | Manual + optional wireless remote |
| Colour | Customer choice |
| Logo | Custom decals available |
Typical Applications
• Urban residential waste collection
• Commercial district garbage removal
• Campus & hospital waste transfer
• Construction site debris handling
Optional Upgrades
• 5 m³ or 8 m³ bins
• Stainless-steel 304 container for food waste
• 220 HP Euro-5 engine
• Container washing system
• GPS bin tracking & camera system
Contact us for pricing and configuration options!
