SINOTRUK HOWO HW76/HW79 CAB SPARE PARTS CATALOG
09 Jul 2025
HOWO truck cabin parts are essential for maintaining the performance and appearance of your HOWO truck. These parts are designed to meet OE standards, ensuring a perfect fit and reliable performance. Whether you need replacement parts or are looking to enhance your truck's functionality, our comprehensive range of cabin parts has you covered.
Basic Info.
仪表 (Instrument)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Sealing strip | AZ1642160010 |
2 | Left defroster duct assembly | AZ1642160011 |
3 | Right side of the defrost duct assembly | AZ1642160014 |
4 | Left air duct assembly | AZ1642160017 |
5 | Left duct fixing bracket assembly | AZ1642160021 |
6 | Right air duct assembly | AZ1642160023 |
7 | Front defrost duct assembly | AZ1642160025 |
8 | Left side of the duct assembly | AZ1642160031 |
9 | Right side of the duct assembly | AZ1642160037 |
10 | Middle-rear duct assembly | AZ1642160042 |
11 | Left front armrest assembly | WG1642160047 |
12 | Right front armrest assembly | WG1642160050 |
13 | Rear armrest | WG1642160052 |
14 | Dashboard crossbeam left | AZ1642160060 |
15 | Dashboard crossbeam right | AZ1642160062 |
16 | Dashboard beam welding assembly | AZ1642160064 |
17 | Beam upper instrument panel bracket assembly | AZ1642160109 |
18 | Right side of the steering column bracket assembly | AZ1642160251 |
19 | Floor bracket assembly | AZ1642160181 |
20 | Plastic pin seat | AZ1642160146 |
21 | Water cupholders front cover | AZ1642160124 |
22 | Trim assembly - Central | AZ1642160138 |
23 | Manhole Cover | AZ1642930010 |
24 | M6 bolt combination with rubber pad | AZ1642930011 |
25 | Driver side dashboard assembly | WG1642160120 |
26 | Outlet assembly | AZ1642160150 |
27 | Assistant driver side dashboard assembly | WG1642160170 |
28 | Deputy driver side instrument audience side cover assembly | WG1642160172 |
29 | Deputy driver side trim assembly | AZ1642160175 |
30 | Co-driver side of the instrument armor assembly | WG1642160177 |
31 | Dashboard cover assembly | WG1642160183 |
32 | Hand brake cover assembly | WG1642160186 |
33 | Hand brake mounting bracket | AZ1642160188 |
34 | Switch panel assembly | WG1642160190 |
35 | Upper cover | WG1642160213 |
37 | Electrical cover assembly | WG1642160215 |
38 | Steering column shroud | AZ1642160217 |
39 | Retainer nut | WG1642930009 |
40 | The left side of the steering column assembly | WG1642160218 |
41 | Right side of the steering column assembly | WG1642160230 |
42 | Left side of the steering column trim assembly | AZ1642160232 |
43 | Right side of the steering column trim assembly | AZ1642160234 |
44 | Footrest assembly station | WG1642160236 |
45 | Left front dashboard cover screws | WG1642160238 |
46 | Right front dashboard cover screws | WG1642160239 |
47 | Hood storage box | WG1642160242 |
48 | Portable ashtray assembly | AZ1642160243 |
49 | Plastic buckle | AZ1642160137 |
50 | Cross recessed pan head screws spring washers assemblies | AZ1642930620 |
51 | Cross recessed pan head screws | Q2140820 |
52 | Cross recessed pan head screws | Q2140516 |
53 | Cross recessed pan head self tapping screws | Q2714816 |
20a | Hex head bolts, spring washers washer assemblies | Q1460825 |
20b | Hex head bolts, spring washers washer assemblies | Q1460620 |
HW76 铺位 (HW76 Berth)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Sleeper assembly | AZ1643570001 |
2 | Hex head bolts | Q150B0825 |
3 | Small Washers | Q40008 |
4 | Sleeper right leg assembly | WG1643570008 |
5 | Hex head bolts | Q150B0825 |
6 | Small Washers | Q40008 |
7 | Sleeper support assembly | WG1643570010 |
8 | Hex head bolts | Q150B0625 |
9 | Small Washers | Q40006 |
10 | Hex head bolts | Q150B0420 |
11 | Small Washers | Q40004 |
HW79 铺位 (HW79 Berth)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Sleeper assembly | AZ1643570001 |
2 | Hex head bolts | Q150B0825 |
3 | Small Washers | Q40008 |
4 | Sleeper right leg assembly | WG1643570008 |
5 | Hex head bolts | Q150B0825 |
6 | Small Washers | Q40008 |
7 | Sleeper support assembly | WG1643570010 |
8 | Hex head bolts | Q150B0625 |
9 | Small Washers | Q40006 |
10 | Hex head bolts | Q150B0420 |
11 | Small Washers | Q40004 |
12 | Sleeper assembly | AZ1644570001 |
13 | Fixed plate assembly | AZ1644570192 |
14 | Rear hinge | AZ1672570020 |
15 | Hex head bolts | Q150B0825 |
16 | Flat Washers | Q40008 |
17 | Pin | Q5100850 |
18 | Cotter | Q5003220 |
13a | Hex head bolts | Q150B0820 |
13b | Flat Washers | Q40108 |
13c | Spring washer | Q40308 |
上窗 (Upper window)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Cover plate for upper window welding assembly | WG1642770006 |
2 | Upper window cover lining | WG1642770008 |
3 | Rivet | WG1642770005 |
4 | Upper window seal | WG1642770009 |
5 | Hinge | WG1642770011 |
6 | Screws | Q2140620 |
7 | Large Washer | Q40206 |
8 | Washer | WG1642930021 |
9 | Switch mechanism | WG1642770007 |
10 | Screws | Q2140620 |
11 | Large Washer | Q40206 |
车窗玻璃 (Window glass)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | HOWO windshield | WG1642710001 |
2 | Windshield seal | WG1642710002 |
4 | Side windows | WG1642710003 |
5 | Side window seal | WG1642710004 |
8 | Rear window | WG1642710005 |
9 | Rear window seal | WG1642710006 |
车门、玻璃及附件 (Door, glass and accessories)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Door guard plate assembly - left door | WG1642330020 |
1a | Door guard plate assembly - the right door | WG1642330040 |
2 | Rivets | AZ1642930005 |
3 | Rivets | AZ1642930006 |
4 | Screw cap | AZ1642930007 |
5 | Cross recessed pan head screws | Q2140620 |
6 | Handle | WG1642330001 |
7 | Shaft circlip | Q43107 |
8 | Left door glass assembly | AZ1642330060 |
8a | Right door glass assembly | AZ1642330061 |
9 | Sealing strip | WG1642330011 |
10 | Outer sealing strip | WG1642330013 |
11 | Door protective layer | AZ1642330019 |
12 | Left glass slide | WG1642330009 |
12a | Right glass slide | WG1642330010 |
13 | Chute seal | WG1642330015 |
14 | Left glass lifter assembly | WG1642330003 |
14a | Right glass lifter assembly | WG1642330004 |
15 | Film | AZ1642330051 |
16 | Cross recessed pan head screws | Q2140612 |
17 | Cross recessed pan head screws | Q2140610 |
18 | Rubber clog | AZ1642930030 |
19 | Left corner window | WG1642350003 |
19a | Right corner window | WG1642350004 |
20 | Left corner window seal | WG1642350001 |
20 | Right corner window seal | WG1642350002 |
30 | Left door assembly with glass, door accessories | AZ1642210001A |
30 | Left door assembly | AZ1642210001 |
30-1 | Left the car door panel assembly | AZ1642210003 |
30-2 | Left door panel assembly | AZ1642210005 |
30-3 | Left door glass guide | WG1642210007 |
30-4 | Door hinge assembly | AZ1642210009 |
30-5 | Hexagon flange bolts | Q1840825 |
40 | Right door assembly with glass, door accessories | AZ1642210002A |
40 | Right door assembly | AZ1642210002 |
40-1 | Right door panel assembly | AZ1642210004 |
40-2 | Right door panel assembly | AZ1642210006 |
40-3 | Right door glass guide | WG1642210008 |
40-4 | Door hinge assembly | AZ1642210009 |
40-5 | Hexagon flange bolts | Q1840825 |
门锁 (Door lock)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Auxiliary support stand | WG1642340020/1, WG1642340020/2 |
2 | Cross recessed countersunk head screws | Q2540820 |
3 | Auxiliary support pin | WG1642340021/1, WG1642340021/2 |
4 | Cross recessed pan head screws | Q2540830 |
5 | Left door stopper assembly | WG1642340012/1, WG1642340012/2 |
5a | Right door stopper assembly (left symmetrically) | WG1642340013/1, WG1642340013/2 |
6 | Left door lock body assembly | WG1642340014/1, WG1642340014/2 |
6a | Right car door lock assembly (left symmetrically) | WG1642340015/1, WG1642340015/2 |
7 | Lock assembly drawing | WG1642340028/1, WG1642340028/2 |
8 | Hex head bolts | Q150B0612 |
9 | Cross recessed pan head screw and washer assemblies | Q2300612 |
10 | Inner opening handle | WG1642340033/1, WG1642340033/2 |
11 | Inner opening assembly / Inner open assembly | WG1642340031/1, WG1642340031/2 |
12 | Inner open lid handle | WG1642340032/1, WG1642340032/2 |
13 | Hex head bolts | Q150B0616 |
14 | Car door handle assembly | WG1642340001/1, WG1642340001/2 |
15 | Gasket | WG1642340002/1, WG1642340002/2 |
16 | Car door key card assembly | WG1642340011/1, WG1642340011/2 |
17 | Left lock lever assembly | WG1642340018/1, WG1642340018/2 |
17a | Right lock lever assembly (symmetric with left parts) | WG1642340029/1, WG1642340029/2 |
18 | Left door lock cylinder assembly | WG1642340008/1, WG1642340008/2 |
18a | Right door lock cylinder assembly (left symmetrically) | WG1642340009/1, WG1642340009/2 |
19 | Lock lever assembly | WG1642340016/1, WG1642340016/2 |
20 | Cross recessed countersunk head screws | Q2540820 |
21 | Latch | Not specified |
26 | Limit pull with assembly | WG1642340026/2 |
27 | Pin | Q5100835 |
28 | Cotter | Q5002526 |
29 | Limit pull with fixing plate | WG1642340027/1, WG1642340027/2 |
30 | Cross recessed pan head screws | Q2140612 |
31 | Waveform Gasket | Q41806 |
遮阳罩 (Sunshield)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | HOWO standard cab Sunshield | WG1642870231 |
1 | HOWO high roof cab sunshield | WG1644870002 |
2 | Right outside the stent / Stand | WG1642870232, AZ1644870003 |
3 | Right in the bracket | WG1642870234 |
4 | Left in the bracket | WG1642870235 |
5 | Left outer bracket / Stand | WG1642870233, AZ1644870003 |
6 | Rubber mat | AZ1672870121 |
7 | Large Washer | Q40208 |
8 | Hex head bolts | Q150B0820 |
9 | Hex nuts | Q340B06 |
10 | Large Washer | Q40206 |
11 | Rubber mat | AZ1642870043, AZ1644870004 |
12 | Shaped pads | AZ1608870008 |
13 | Screws | Q2140625 |
14 | Outer lower bracket | WG1642870236 |
15 | Hex head bolts | Q150B0820 |
16 | Large Washer | Q40208 |
17 | Rubber mat | AZ1672870121 |
18 | Hex head bolts | Q150B0825 |
19 | Large Washer | Q40208 |
20 | Hex nuts | Q340B08 |
下视镜 (Down-view mirror)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Under endoscopic | WG1642770004 |
2 | Screw nut | WG1642770004-1 |
3 | Spring washers | WG1642770004-2 |
4 | Down-view mirror support | AZ1642770054 |
4 | Down-view mirror support (HW79) | AZ1644771000 |
4 | Down-view mirror support (HW79 right drive) | AZ1646771000 |
4 | Down-view mirror support (right drive) | AZ1646770054 |
5 | Hex head bolts | Q150B0825 |
6 | Spring washer | Q40308 |
7 | Large Washer | Q40208 |
8 | A type hexagon nuts | Q340B08 |
11 | Pavement mirror assembly | WG1600770007 |
12 | Floor | AZ1642770098 |
13 | Screws | Q2540620 |
14 | Hexagon socket head cap screws | Q218B0616 |
15 | Spring washer | Q40306 |
后视镜 (Rear view mirror)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Rubber block | WG1642770001-1 |
2 | Hexagon socket head cap screws | Q218B0635 |
3 | Rubber parts | WG1642770001-2 |
4 | Decorative cover block | WG1642770001-3 |
5 | Left rear view mirror | WG1646770001 |
6 | Right rear view mirror | WG1646770002 |
7 | Rubber block | WG1642770003-1 |
8 | Rubber block | WG1642770003-2 |
9 | Decorative Cover | WG1642770003-3 |
10 | Down left rear view mirror | WG1642770001-4, WG1646770001-4, WG1646770002-4 |
10 | Down right rear-view mirror | WG1642770003-4 |
11 | Upper left rearview mirror | WG1642770001-5, WG1646770001-5 |
11 | Upper right rearview mirror | WG1642770003-6, WG1646770002-6 |
保险杠 (Bumper)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Left bumper decorative plates | AZ1642240050 |
1a | Bumper right decorative plates | AZ1642240051 |
1b | Retainer nut | WG1642930009 |
1c | Rubber mat | AZ1608240074 |
2 | Screws | Q2714819 |
3 | Large Washer | Q40206 |
4 | Bumper assembly | WG1642240002 |
4 | High bumper | WG1641240001 |
5 | Hex head bolts | Q150B0835 |
6 | I type hexagon nuts | Q340B08 |
7 | Large Washer | Q40208 |
8 | Spring washer | Q40508 |
9 | Plug right inside cover / Right outside the block cover | WG1642240050, WG1642240052 |
9 | Plug cap left / Left outer block cover | WG1642240051, WG1642240053 |
10 | Left bracket assembly / Right bracket assembly | WG1642240040, WG1642240041 |
11 | Middle bracket | WG1642240042 |
12 | Screws | Q2764816 |
挡泥板 (Fender)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Left fender | WG1642230012, WG1641230020 |
2 | Right fender / Right fender assembly | WG1642230013, WG1641230021 |
3 | Hex head bolts | Q150B0620 |
4 | Washer | Q40106 |
5 | Spring washer | Q40306 |
6 | Screw nut | Q340B06 |
7 | Left skid plate | WG1642230018 |
7a | Right cleat | WG1642230019 |
8 | Cross recessed pan head screws | Q2540830 |
9 | Pedal bracket (upper bumper) / Pedal bracket | AZ9725930049, WG9725930017 |
10 | Right pedal | WG1641240011 |
10 | Left pedal | WG1642240030 |
10a | Left Pedal / Right pedal | WG1641240012, WG1642240031 |
11 | Hex head bolts | Q150B0825 |
12 | Screw nut | Q340B08 |
13 | Spring washer | Q40308 |
14 | Left rear fender | WG1642230003 |
15 | Right rear fender | WG1642230004 |
15a | Fender stiffeners | WG1642230005 |
16 | Washer | AZ1642230008 |
17 | Liner (rear fender) | AZ1642230007 |
18 | Self-tapping screws | Q2713516 |
19 | Hex head bolts | Q150B0860 |
19a | Hex head bolts | Q150B0620 |
20 | I type hexagon nuts | Q340B08 |
20a | I type hexagon nuts | Q340B06 |
21 | Spring washer | Q40308 |
21a | Spring washer | Q40306 |
21b | Washer | Q40106 |
22 | Left skid plate | WG1642240032 |
22a | Right cleat | WG1642240033 |
22b | Cross recessed pan head screws | Q2540830 |
22c | Spring washer | Q40308 |
22d | Screw nut | Q340B08 |
23 | Left rear fender bracket | WG9719930315, WG9731930010 |
24 | After the right fender bracket | WG9731930015, WG9719930313 |
24a | Plate | WG9731930014 |
25 | Hex head bolts | Q151B1445 |
26 | Self-locking nuts | 190003888468 |
27 | Tailgate assembly | WG1641230028 |
28 | Connecting bracket | WG1641230030 |
29 | Cross recessed tapping screws | Q2714816 |
30 | Hex head bolts | Q150B0620 |
41 | Left front fender | WG1641230025 |
42 | Right front fender | WG1641230026 |
43 | Fenders with layering | AZ1641230027 |
侧导流罩 (Side guide hood)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Right guide hood outer panel assembly | WG1642110001 |
1a | Left guide hood outer panel assembly | WG1642110002 |
2 | Right wind shield inner plate | WG1642110003 |
2a | Left wind shield inner plate | WG1642110004 |
3 | Upper connecting plate assembly | AZ1642110006 |
4 | Right lower connecting plate | AZ1642110007 |
4a | Left lower connecting plate | AZ1642110008 |
5 | Hexagon thin nuts | Q350B06 |
5a | Large Washer | Q40206 |
5b | Spring washer | Q40306 |
6 | Hex head bolts | Q150B0620 |
6a | Large Washer | Q40206 |
6b | Spring washer | Q40306 |
7 | Hex head bolts | Q150B0820 |
7a | Large Washer | Q40208 |
7b | Spring washer | Q40308 |
10 | Decorative plate left A column | WG1642110019 |
10a | Decorative plate right A column | WG1642110020 |
12 | A column retaining clip | WG1642110021 |
13 | A column fixed plastic rivets | WG1642110022 |
前盖 (Front cover)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Radiator mask | WG1642110013 |
2 | Company logo | AZ1646950001 |
3 | Wordmark | AZ1646950002 |
4 | Mask right lock assembly | WG1642110027 |
5 | Masks left lock assembly | WG1642110028 |
6 | Hex head bolts | Q150B0616 |
7 | Large Washer | Q40206 |
8 | Hinge mount bracket assembly | AZ1642110014 |
9 | Hexagon socket head cap screws | Q218B0870 |
10 | Small Washers | Q40008 |
11 | Protective strip | WG1642110018 |
12 | Hinge Block | WG1642110016 |
13 | Left hinge welding assembly | AZ1642110032 |
14 | Right hinge welding assembly | AZ1642110033 |
15 | Hinge pin | AZ1642110017 |
16 | Block cover | WG1642930003 |
17 | Right air spring support bolt | WG1642110024 |
18 | Spacer rings | WG9100360134 |
19 | Cotter | Q5002014 |
20 | Hex head bolts | Q150B0616 |
21 | Large Washer | Q40206 |
22 | Hex head bolts | Q150B0816 |
23 | Large Washer | Q40208 |
24 | Flap | WG1642110034 |
HW76/HW79 工具箱 (HW76/HW79 Tool box)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Upper window plate welding assembly | WG1642270006 |
2 | Toolbox hinge assembly | WG1642290002 |
3 | Hexagon flange bolts | Q1840612 |
4 | Toolbox latch assembly | WG1642290005 |
5 | Hexagon head screws Flower | Q2100612 |
6 | Hexagon head screws | Q218B0616 |
7 | Single-tube clip | Q68108 |
8 | Toolbox lock assembly | WG1642290003 |
9 | Plate | WG1642290004 |
10 | Seal Kit | WG1642290006 |
卡带播放器 (Cassette players)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Cassette players (automatically turn with the LCD display) | WG9130780026 |
1 | CD, cassette player | WG9719780002 |
4 | Speaker | WG9719780003 |
5 | Cab roof wiring harness | AZ9719770006, AZ9719770003 |
9 | Feeder (200cm) | WG9130780001 |
25 | Cross recessed tapping screws elbow | Q2714216 |
26 | Small Washers | Q40004 |
27 | Spring nut | 1900039699563 |
导流罩和挡风玻璃 (Shroud & Windshield)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Shroud assembly | WG1642870141 |
2 | Supports | AZ1642870145 |
2a | Hex head bolts | Q150B0820 |
2b | Large Washer | Q40208 |
2c | Spring washer | Q40308 |
3 | Bracket welding assembly | AZ1642870143 |
3a | Rubber mat | AZ1672870121 |
3b | Hex head bolts | Q150B0820 |
3c | Large Washer | Q40208 |
3d | Spring washer | Q40308 |
4 | Front bracket | AZ1642870148 |
4a | Hex head screw bolt hole | Q173B0870 |
4b | Cotter | Q5002020 |
4c | Large Washer | Q40208 |
4d | Serrated lock washers | Q41208 |
4e | I type hexagon nuts - fine tooth | Q241B08 |
5 | After the stent | AZ1642870146 |
5a | Hex head screw bolt hole | Q173B0870 |
5b | Cotter | Q5002020 |
5c | Large Washer | Q40208 |
5d | Serrated lock washers | Q41208 |
5e | I type hexagon nuts - fine tooth | Q341B08 |
6 | Side stand | AZ1642870147 |
6a | Hex head screw bolt hole | Q173B0870 |
6b | Cotter | Q5002020 |
6c | Serrated lock washers | Q41208 |
6d | I type hexagon nuts - fine tooth | Q341B08 |
6e | Large Washer | Q40208 |
6f | Hex head bolts | Q150B0820 |
7 | Left bracket / Right upper bracket / Side deflector bracket (on) | WG1644870013, WG1644870019, AZ1642870153 |
7a | Hex head bolts | Q150B0820 |
7b | Large Washer | Q40208 |
7c | Spring washer | Q40308 |
8 | Under the deflector (right) | WG1644870011 |
8a | Lower baffles (left) | AZ1644870012 |
9 | Side deflector bracket (in) | AZ1642870014 |
9a | Hex head bolts | Q150B0820 |
9b | Large Washer | Q40208 |
9c | Spring washer | Q40308 |
10 | Lower bracket (right) | AZ1644870015 |
10a | Lower bracket (left) | AZ1644870018 |
10b | Hex head bolts | Q150B0820 |
10c | Large Washer | Q40208 |
10d | Spring washer | Q40308 |
11 | Rubber shock pad | AZ1630230125 |
12 | Rubber mat | AZ1672870121 |
13 | Nut plate assembly | AZ1642930061 |
20 | Spoiler | WG1644870016 |
21 | Deflector on the side bracket | WG1644870017 |
22 | Deflector bracket | WG1644870020 |
翻转机构 (Rotating mechanism)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Hydraulic hand pump | WG9719820001, WG9719826001 |
2 | Hex head bolts | Q150B1020 |
3 | Spring washer | Q40310 |
4 | Cab lift cylinder | WG9719820002 |
5 | Single elbow high pressure hose (2600) | WG9719821005, WG9719820005 |
6 | Single elbow high pressure hose | WG9719820006 (1060), WG9719821006 (600) |
7 | Double elbow high pressure hose (3150) | WG9719820007 |
8 | Single elbow hose | WG1642440075 |
9 | joint | 190003559482 |
10 | Cab tilting cylinder support shaft | AZ9719820008 |
11 | Bush | AZ9719820009 |
12 | Large Washer | Q40216 |
13 | Bush | AZ9719820012 |
14 | Self-locking nuts | 190003888459 |
15 | Straight-grease nipple | Q700B06 |
16 | Cab lifting cylinder support shaft | AZ9719820010 |
17 | Large washer | WG9719820011 |
18 | Flat Washers | Q40124 |
19 | Double elbow hose (3500) | WG1642440072 |
20 | Self-locking nuts | Q33424 |
21 | Washer | WG9719820013 |
22 | Stay on | AZ9719820021 |
23 | Pin (h11) | Q5101428 |
24 | Flat Washers | Q40114 |
26 | Wave spring washers | Q41814 |
27 | Under stays | AZ9719820022 |
28 | Pin | 190003903452 |
29 | Saddle-shaped spring washers | Q41710 |
30 | Cotter | Q5003216 |
31 | Cotter | Q5004028 |
32 | Flat Washers | Q40112 |
33 | Plastic fastening tape | 190003171356 |
雨刮器 (Wiper)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
0 | Wiper assembly (containing 1 to 5) | WG1642740002, WG1646740002 |
1 | Rod assembly | WG1642740009/1, WG1642740009/2, WG1646740009 |
2 | Wiper arm assembly | WG1646740001, WG1642740010/1, WG1642740010/2 |
3 | Blade assembly | WG1642740011/1, WG1642740011/2 |
4 | Wiper motor | WG1642740008/1, WG1642740008/2 |
5 | Flange lock nut | Q33010 |
6 | Motor bracket | WG1642740003/1, WG1642740003/2 |
7 | Hexagon thin nuts | AZ1642740004 |
8 | Thin washers | AZ1642740005 |
9 | Bearing assembly | AZ1642740006 |
10 | Cover | AZ1642740007 |
11 | Hex head bolts | Q150B0812 |
12 | Flat Washers | Q40108 |
13 | Spring washer | Q40308 |
14 | Hex head bolts | Q150B0616 |
15 | Spring washer | Q40306 |
16 | Flat Washers | Q40126 |
挡风玻璃洗涤机构 (Windshield wash mechanism)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | I type hexagon nuts | Q340B06 |
2 | Spring washer | Q40306 |
3 | Windshield washer container holder | AZ1646860005, AZ1642860009 |
4 | Windshield washer assembly | WG1642860001/1, WG1646860001 |
4-1 | Washer pump | WG1642860001-1 |
4-2 | Cover | WG1642860001-2 |
5 | Spring washer | Q40308 |
6 | I type hexagon nuts | 340B08 |
7 | Hex head bolts | Q150B0625 |
8 | Large Washer | Q40206 |
9 | Large Washer | Q40208 |
10 | Hex head bolts | Q150B0830 |
11 | Over board retainer | AZ1642860007 |
12 | Hose | AZ1642860003 |
13 | V-type fittings | 116100770121 |
14 | Hose | AZ1642860005 |
15 | Hose | AZ1642860004 |
16 | Two-way connector | AZ1600860121 |
17 | Wire bundle clamps | WG1600860008 |
18 | Bracket assembly | AZ1646860004 |
驾驶室后悬架 (Rear suspension of cab)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Hexagon flange bolts | Q1841230 |
2 | Left upper bracket assembly | WG1642440040 |
3 | Right upper bracket assembly | WG1642440041 |
4 | Cab lock signal switch | WG1642440052 |
5 | Hex head bolts | Q150B0630 |
6 | Hydraulic lock assembly | WG1642440101 |
7 | Spring washer | Q40306 |
8 | Hex head bolts | Q150B0610 |
9 | Putter left bracket | WG1642440055 |
10 | Right putter stand | WG1642440056 |
11 | Full Metal hex flange self-locking nut | Q33014 |
12 | Rear suspension shock absorbor | AZ1642440025, AZ1642440027, WG1642440028 |
13 | Hexagon flange bolts | Q1841480 |
14 | Full Metal hex flange self-locking nut | Q33014 |
15 | Hexagon flange bolts | Q1841470 |
16 | Hex head bolts | Q151B1445 |
17 | Self-locking nuts | 190003888458 |
18 | Hex head bolts | Q150B0850 |
19 | Large Washer | Q40208 |
20 | Height control valve assembly | WG1642440051 |
21 | Plate | AZ1642440035 |
22 | Hexagon flange bolts | Q1841490 |
23 | Stopper washer | AZ1642430082 |
24 | Hexagon flange bolts | Q18414140 |
25 | Bush | AZ1642440032 |
26 | Lateral stability shock absorbor assembly | AZ1642440021 |
27 | Bush | AZ1642440031 |
28 | Full Metal hex flange self-locking nut | Q33014 |
29 | Stopper assembly | WG1642430081 |
30 | I type hexagon nuts | Q340B10 |
31 | Hemisphere gasket | AZ1642430036 |
32 | I type hexagon nuts | Q340B06 |
33 | Pushrod assembly II | WG1642440060 |
34 | Pin | Q5100614 |
35 | Cotter | Q5002012 |
36 | Left bracket | AZ1642440011, AZ1642440013, AZ1642440015 |
37 | Right bracket / Right lower bracket | AZ1642440012, AZ1642440014, AZ1642440016 |
38 | Joint body | WG1642440070 |
39 | Double elbow hose | Not specified |
驾驶室前悬架 (Front suspension of cab)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Air spring bracket assembly / Upper support | AZ1642430030, AZ1642430125 |
2 | Spring washer | Q40310 |
3 | Hex head bolts | Q150B1025 |
4 | Hex head bolts | Q150B0820 |
5 | Serrated lock washers | Q41208 |
6 | Guide cone block / Gasket | WG1642430033, AZ1642430116 |
7 | Air spring assembly / Coil spring assembly | AZ1642430085, WG1642430118, WG1642430117 |
8 | Spring washer | Q40308 |
9 | Hex head bolts | Q150B0820 |
10 | Pipe joint assembly | WG1642430086 |
11 | Cover | AZ1642430043 |
12 | Spring washer | Q40312 |
13 | Hex head bolts | Q150B1235 |
14 | Left front cab support bracket | AZ1642430041 |
15 | Lower left front suspension bracket assembly | WG1642430010, AZ1642430110, AZ1642430126 |
16 | Hex head bolts (fine tooth) | Q151C1235 |
17 | Bolt | AZ1642430071 |
18 | Left arm assembly | AZ1642430051 |
19 | Shaped washer | AZ1642430072 |
20 | Self-locking nuts | 190003888459 |
21 | Self-locking nuts | 190003888457 |
22 | Self-locking nuts | 190003888457 |
23 | Right front suspension bracket assembly | WG1642430020, WG1642430120, AZ1642430127 |
24 | Large Washer | Q40208 |
25 | Hex head bolts | Q150B0855 |
26 | Height control valve assembly | WG1642440051 |
27 | Push rod | WG1642430035 |
28 | I type hexagon nuts | Q340B09 |
29 | Hemisphere gasket | AZ1642430036 |
30 | Push rod connecting rod | AZ1642430034 |
31 | A type hexagon nuts | Q340B08 |
32 | Serrated lock washers | Q41208 |
33 | A type hexagon nuts | Q340B08 |
34 | Cotter | Q5002012 |
35 | Pin | Q5100614 |
36 | Right arm assembly | AZ1642430052 |
37 | Hex head bolts | Q151B1645 |
38 | Cab right front support bracket (left symmetrically) | AZ1642430042 |
39 | Self-locking nuts | 190003888459 |
40 | Full Metal hex flange self-locking nut | Q33014 |
41 | Front shock a... | Not specified |
空调 (Air conditioning)
序号 (Sequence) | 名称 (Name) | 零件号 (Part No.) |
1 | Air conditioner assembly | WG1642820002 |
1-1 | Lower case | AZ1630840013 |
1-2 | Drip tube | AZ1630840091 |
1-3 | Electronically controlled valve for radiator assembly | AZ1630840319 |
1-3-1 | Heat sink | AZ1630840074 |
1-3-2 | Inlet assembly | AZ1630840073 |
1-3-3 | O-ring | AZ1630840066 |
1-3-4 | Outlet assembly | AZ1630840072 |
1-3-5 | Valve assembly (electronically controlled) | AZ1630840320 |
1-4 | 3 # steering valve | AZ1630840326 |
1-5 | Screws | Q2723525 |
1-6 | HVAC | AZ1642820010 |
1-6-1 | Expansion valve | AZ1642820010-1 |
1-6-2 | Temperature Sensor | AZ1642820010-2 |
1-8 | The housing | AZ1630840312 |
1-9 | I foam seal | AZ1630840092 |
1-10 | Clamp connection | AZ1630840063 |
1-11 | Fan assembly | AZ1642820010 |
1-12 | Fan wiring harness assembly | AZ1630840323 |
1-13 | Screws | Q2714216 |
1-14 | Blower block assembly (Nanjing Austrian) | AZ1630840321 |
1-16 | Rotating arm | AZ1630840050 |
1-17 | Torsion | AZ1630840051 |
1-18 | Large washer | AZ1630840052 |
1-19 | Snap ring | AZ1630840065 |
1-20 | Link shaft | AZ1630840045 |
1-21 | Link shaft | AZ1630840046 |
1-22 | Link shaft | AZ1630840047 |
1-23 | 2 # steering | AZ1630840325 |
1-24 | Screws | Q2723525 |
1-25 | Arm | AZ1630840313 |
1-26 | Crank pulling shaft | AZ1630840314 |
1-27 | Lotus seat | AZ1630840053 |
1-28 | The housing | AZ1630840311 |
1-29 | Self-adhesive gasket outlet Ⅱ | AZ1630840401 |
1-30 | Foam seal | AZ1630840093 |
1-31 | Clamp connection | AZ1630840063 |
1-32 | Left throttle | AZ1630840037 |
1-34 | Front flap | AZ1630840040 |
1-35 | Link shaft | AZ1630840041 |
1-36 | Square shaft | AZ1630840035 |
1-37 | After the throttle | AZ1630840036 |
1-38 | Crank pulling shaft | AZ1630840039 |
1-39 | Lotus seat | AZ1630840053 |
1-40 | Bevel gear sector | AZ1630840034 |
1-42 | Open ring | Q43660 |
1-43 | 1 # diverter (Radical 182 damper) | AZ1630840324 |
1-44 | Screws | Q2723525 |
1-45 | Inlet seal ring | AZ1630840016 |
1-46 | Retaining plate | AZ1630840021 |
1a | Hex head bolts | Q150B0830 |
1b | Spring washer | Q40308 |
1c | Large Washer | Q40208 |
3 | Flat rubber sealing sleeve | AZ1630840062 |
4 | Screws | Q2714825 |
4a | Large Washer | Q40206 |
5 | Hose clamps | 190003989340 |
6 | Hose | WG1642840091 |
7 | Pipe assembly | AZ1642840013 |
8 | Hexagon flange bolts | Q1840816 |
9 | Air inlet grille assembly | AZ1642840084 |
10 | Hex head bolts | Q150B0620 |
11 | Hexagon flange bolts | Q1840825 |
11a | All-metal hexagon nuts with flange | Q33008 |
12 | Forming hose | WG1642840092 |
13 | Hex head bolts | Q150B0640 |
13a | Spring washer | Q40306 |
13b | Large Washer | Q40206 |
14 | Condenser assembly | WG1630820073 |
15 | Left condenser bracket assembly | WG1642820011, WG1642828011 |
15 | Right condenser bracket assembly | WG1642820012 |
15a | Right condenser bracket assembly | WG1642828012 |
16 | Hex head bolts | Q150B0825 |
16a | Spring washer | Q40308 |
16b | Large Washer | Q40208 |
16c | A type hexagon nuts | Q340B08 |
17 | Hose | WG1642820017 |
18 | Steam - pressure hose assemblies | WG1642820019, WG1642828019 |
19 | Hex head bolts | Q150B0625 |
19 | Spring washer | Q40306 |
19 | Large Washer | Q40206 |
20 | Accumulator assembly | WG1642820015 |
21 | High pressure steam pipe | WG1642820018/1 |
22 | Hose | WG1642820016, WG1642828016 |
23 | Rubber bushing | WG1630820019 |
24 | Control panel assembly | WG1630840032 |
25 | Temperature sensor assembly | WG1630820313 |
26 | Air conditioning wiring harness assembly | AZ1630820312 |
70 | Refrigeration Compressors | WG1500139000 |
70-1 | Refrigeration compressor | WG1500139000/3 |
71 | Bushings | 1581C160018 |
72 | Bracket | AZ1500130018, AZ1500130107 |
73 | Hex head bolts | Q150B10130 |
74 | Spacer plates | 161500130027 |
76 | Hex head bolts | Q150B0825 |
78 | Wave spring washers | Q41808 |
79 | Tightening bolts | AZ1500090026, AZ1500130105 |
80 | Flat Washers | Q40110 |
81 | Hex nuts | Q340B10 |
82 | Type 2 all-metal hexagon nuts | Q33208 |
83 | V-belts | WG1500130110 |
83-1 | V-belts | WG1500130016/3 |
