Size (mm)

9500 x 2500 x 3950

Tires

12R22.5, 10+1pcs, rim trim cover

Wheelbase

3775+1400mm

Axle

MAN9.5T front axle，MAN13T rear axle, speed ratio:5.92

Engine

Model

WP10.340E22, Euro II, Diesel

Engine power

250KW (340HP) @ 2200 tr / min

Max torque

1250 N.m @ 1400-1600 tr / min

Air intake type

turbo-charge and inter-cool

Minimum fuel consumption

≤ 196/ kW .h

Fuel injection type

Direct injection

PTO

Include

Transmission

RTD11509C Transmission, 9 forward speeds + 1 reverse speeds

Fuel tank

380L Steel fuel tank

Suspension

Multiple front and rear springs, four main plates + four riding bolts

Main beam

Double-layer frame 850×300（8+7）

Tank Specs

Tank Volume (m³)

10

Speed reduction system

Top

Hydraulics pump

ARK

Hydraulics motor

ARK

Other

F3000 medium-length flat-top cab without roof deflector, hydraulic main seat, four-point hydraulic suspension, rearview mirror, hot zone air conditioner, electric window opener, manual flip, metal bumper-light guard net, three-level Get on the pedal,

Air filter, ordinary exhaust, oil pan protective grille, imported clutch, taillight protective grille, 165Ah maintenance-free battery, elastic headrest, manual sunroof, telescopic shaft control,

Six-channel ABS, front lower protection, driving recorder, cruise control system, speed limit 90km/h, seat belt not fastened reminder, reflective vest, SHACMAN logo, full English logo, special signage
