Product Name: Engine Front Bracket Support Cushion (Left Front Shock Absorber Pad)
OEM Number: DZ95259590077
Brand: SHACMAN (Shaanxi Automobile Group)
Application: SHACMAN Delong M3000 series heavy duty trucks (left front engine mounting position)

--- WHAT IT IS ---

The DZ95259590077 is a rubber cushion block, also known as an engine front bracket support cushion or left front shock absorber pad. It is installed between the engine front bracket and the chassis frame on SHACMAN Delong M3000 heavy duty trucks.

This component serves as a vibration isolator and shock absorber for the engine's front mounting point. It is made of high grade natural or synthetic rubber with internal metal reinforcement. The cushion compresses under engine load, absorbing road shocks and isolating engine vibration from the chassis.

--- THE PROBLEM IT SOLVES ---

Heavy duty truck engines generate substantial vibration and are subject to constant road shocks. Over time, the original rubber support cushion hardens, cracks, or permanently compresses. A worn or collapsed cushion causes metal to metal contact between the engine bracket and the frame, resulting in severe vibration transmitted to the cab, increased noise, accelerated wear on other engine mounts, and potential damage to the front bracket itself.

The left front position is particularly stressed because engine torque reaction during acceleration often loads this corner first. When the cushion fails, drivers experience a rough ride, dashboard rattles, and possible misalignment of the engine cooling fan with the shroud.

This replacement cushion restores proper vibration isolation, eliminating metal on metal contact and smoothing engine operation.

--- WHY CHOOSE THIS UNIT ---

Genuine SHACMAN specification ensures the exact rubber compound, durometer (hardness), and dimensional fit. The cushion is engineered to provide the correct compression rate under the weight of the engine while still absorbing shock.

It features internal metal inserts or bonded steel plates (as per original design) to prevent extrusion of the rubber under bolt torque. The material is formulated to resist oil, grease, and extreme temperatures ranging from -40°C to +100°C.

This part is specifically for the left front position. Direct replacement requires no modification, using the original bolts and mounting holes.

The cushion restores original engine height and alignment, preventing fan to shroud contact and ensuring proper driveline angles.

--- TECHNICAL DETAILS ---

OEM Number: DZ95259590077
Component Type: Engine front bracket support cushion / shock absorber pad / rubber buffer
Position: Left front (driver side) engine mount
Material: High quality natural rubber or EPDM with internal metal reinforcement
Durometer (Hardness): OEM specification (typically 60 to 75 Shore A)
Load Capacity: Designed for front engine weight of approx. 500 to 800 kg per side
Operating Temperature: -40°C to +100°C
Mounting: Through bolt with metal sleeve or studs
Function: Isolate vibration, absorb shock, prevent metal to metal contact
Color: Black

--- PRODUCT PARAMETERS ---

Condition: New
Warranty: 12 months
Applicable Industries: Heavy duty truck fleet maintenance, auto repair shops, commercial vehicle parts wholesale
Weight: Approximately 0.8 to 1.2 kg
Video outgoing-inspection: Available upon request
Machinery Test Report: Available upon request
Marketing Type: Regular product (OEM grade)
Standard or Nonstandard: Standard (OEM specification)
Structure: Bonded rubber to metal (elastomer with steel reinforcement)
Body Material: Rubber compound with metal insert(s)
Place of Origin: Shaanxi, China
Brand Name: SHACMAN (OEM grade)
Product Name: Engine Front Bracket Support Cushion
OE Number: DZ95259590077
Color: Black
Quality: High-Quality (OEM grade)
Package: Neutral carton with plastic bag or foam protection
Delivery time: 7 to 15 working days after order confirmation
Payment terms: T/T, Western Union, PayPal
MOQ: 1 piece
Sample: Available (customer pays shipping)

--- MATERIAL COMPOSITION ---

Rubber Compound: High strength natural rubber or EPDM (oil and heat resistant)
Metal Inserts: Painted or zinc plated steel plates or sleeves
Bonding: Chemically bonded rubber to metal for permanent adhesion
Hardware: Internal threaded or unthreaded sleeves for bolt passage

--- COMPATIBLE VEHICLE APPLICATIONS ---

Confirmed fitment (verify by VIN or original part):

SHACMAN Delong M3000 series heavy duty trucks (all variants: tractor, dump truck, concrete mixer, cargo truck) left front engine bracket position

May also be used on other SHACMAN Delong models (X3000, F3000) but always verify by comparing the old part.

Note: This is the left front cushion. Right front may have a different part number. Always confirm orientation and check the original part number DZ95259590077 before ordering.

--- INSTALLATION NOTES ---

Raise the front of the vehicle and safely support the chassis. Use a jack to support the engine weight at the front.

Remove the bolt or nuts securing the engine front bracket to the cushion.

Lift the engine slightly (a few millimeters) to relieve pressure on the cushion.

Remove the old compressed or cracked cushion. Clean the mounting surfaces on the bracket and the frame.

Position the new cushion in place. Ensure the metal sleeve or stud aligns correctly.

Lower the engine onto the cushion. Install the bolt or nut and torque to SHACMAN factory specification (typically 90 to 120 Nm for M16 bolts).

Check that the cushion is centered and not under side load.

Start the engine and check for abnormal vibration. Inspect after 100 km and retorque if necessary.

Professional installation recommended. Full torque chart available digitally upon request.

--- WHEN TO REPLACE ---

Replace the cushion if you observe visible cracks or chunks missing from the rubber, permanent compression (cushion thickness reduced by more than 20 percent), evidence of metal to metal contact (shiny wear marks on bracket or frame), oil soaking that has softened the rubber, or excessive engine vibration felt in the cab at idle.

Inspection during every oil change is recommended for heavy duty vehicles, and replacement typically every 200,000 to 300,000 km depending on operating conditions.

--- PACKAGING AND DELIVERY ---

Packaging: Neutral carton with plastic bag or foam padding
MOQ: 1 piece
Delivery Time: Regular orders within 24 to 48 hours. Bulk orders require 5 to 10 working days
Place of Origin: Shaanxi, China
Payment Terms: T/T, Western Union, PayPal
Shipping Terms: EXW, FOB Qingdao, CFR, CIF, DDU

--- CONTACT ---

Sales Manager: William
Phone / WeChat: +86 19050562894
Email: Sales22@chinatruck.cc
Company: Authorized commercial vehicle parts supplier

--- WARRANTY AND OFFERS ---

12 month warranty against manufacturing defects.
Free basic installation guidance (digital document) upon request.
Bulk order discounts available for 10 pieces or more.
Express shipping available for urgent replacement needs.
Free VIN based compatibility check before ordering.
