SHACMAN 380hp lorry cargo truck hot sale

No.: George 171203

Vehicle Type: Cargo Truck

Brand Name: SHACMAN

Shacman Trucks

Person in charge: George Jiang

Cel: 0086 176 6971 7510

Whatsapp: 8615866821829

E-mail: sales35@chinatruck.cc

FREE GET QUOTE

Details

Person in charge: Mr. George Jiang

Tel: 0086-17669717510

Cel:0086-532-6608 7516
E-mail: sales35@chinatruck.cc

Truck summary parameter

Construction shacman D-LONG F3000 310hp lorry truck

Model

SX3254JN294

Max. laden mass (kg)

12400

Kerb mass (kg)

12600

Max. total mass (kg)

25000

Max. speed (km/h)

77

Min. turning diameter  (m)

24

Min. ground clearance (mm)

314

Max. gradeability (%)

25

Appearance

dimensions

(mm)

Max. Length

7380

Max. Width

2490

Max. Height

3500

Wheel base (mm)

2925

Overhang(front/rear)

1525/1580

Track width (mm) (front/rear)

2048/1800

Engine

WD615.31  EURII

Output power  ps r. p. m

310 /2200

Torque  N.m r. p. m

1250/1300-1500

Cylinder bore×Engine stroke (mm)

126×130

Compression ratio

15.5:1

Fuel consumption for 100km (L)

36

Dimensions of dump body(L×W×H)

4725×2300×1200

Fuel tank capacity (L)

200

Clutch

GF420 Single-plate, air-assisted, mechanically operated, spring type

Gearbox

Transmission

Fuller 9JS1135

Gear ratio

12.11  8.08  5.93  4.42  3.36  2.41  1.76  1.32  1.00  12.66 (R)

Front axle

MAN V9-75L disc type front axle

Rear axle

Punching-welding axle housing, double reduction driving axle,   inter-wheel differential and differential lock

Frame

300mm*80mm*8mm(inner: 280mm*70mm*7mm) or

243mm*80mm*8mm(inner: 218mm*70mm*7mm)

Suspension


Front

Longitudinal semi-elliptic leaf spring type with telescopic absorber

Rear

Longitudinal parabolic leaf spring balance type

Steering

ZF8098 Integral type power-steering

Cab

F3000 flat roof cabin with A/C
