Heavy-Duty Semi-Trailer Configuration Sheet – Front, Rear & Middle Units (Non-Chinese Announcement)
No.:
Vehicle Type: Semi-Trailer
Brand Name: CIMC
Person in charge: William Du
Cel: 8619050562894
Whatsapp: 8619050562894
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
Configuration Sheet – Heavy-Duty Semi-Trailer Units (Front / Rear / Middle)
| No. | Part / Parameter | Front Trailer | Rear Trailer | Middle Trailer |
|---|---|---|---|---|
| 1 | Announcement model | Not in Chinese catalogue | — | — |
| 2 | Girder structure | W-shape, through-type | — | — |
| 3 | Side beam | 180 mm wide 18# channel steel | — | — |
| 4 | Cross beam | W-shape, through-type | — | — |
| 5 | Floor | 3 mm thick chequered plate | — | — |
| 6 | Axle spec / qty | 16 T normal wheel-base 1 840 mm, 3 axles | 16 T normal wheel-base 1 840 mm, 2 axles | — |
| 7 | Tyre spec / qty | 12.00R20-18PR Linglong 13 pcs | 12.00R20-18PR Linglong 8 pcs | — |
| 8 | Rim spec / qty | 8.8-20 enhanced 13 pcs | 8.8-20 enhanced 8 pcs | — |
| 9 | Leaf spring / sets | 12 pcs 16 mm × 120 mm 6 sets | 12 pcs 16 mm × 120 mm 4 sets | — |
| 10 | Suspension | HuaJun reinforced heavy-duty | — | — |
| 11 | Support / qty | 28 T Fuwo single-action 1 set | 8 T Fuwo single-action 1 set | — |
| 12 | Traction pin / qty | 90# welded 16 mm 1 pc | 90# welded 12 mm 1 pc | 90# welded 12 mm 1 pc |
| 13 | Brake pump / qty | 4 double + 2 single cavities | 2 double + 2 single cavities | — |
| 14 | Brake valve / qty | Domestic 6-hole relay 1 pc | Domestic 4-hole relay 1 pc | — |
| 15 | Spare tyre rack | #281 standard 2 pcs (front + rear) | — | — |
| 16 | Toolbox | Custom toolbox 1 pc each side (right) | — | — |
| 17 | Saddle / qty | #90 Shenchi 1 pc | — | #90 Shenchi 1 pc |
| 18 | Locking devices / qty | 20' container locks 8 pcs | — | — |
| 19 | Paint | Frame sand-blast + primer + top-coat ≥ 60 μm | ||
| 20 | Circuit | 24 V, 7-pin sealed harness | ||
| 21 | Lamps | LED | ||
| 22 | Fender | Split (non-one-piece) |
Quality & Compliance
Paint film ≥ 60 μm for corrosion resistance
24 V sealed wiring for harsh environments
LED lighting for high visibility & low power draw
Split fenders for easier tyre access
Delivery & Support
Lead time: 7–15 days for complete trailer
Global shipping: 25–35 days sea freight
Spare parts kit available within 48 h
