FOTON TOANO AMBULANCE 3.0L DIESEL EMERGENCY MEDICAL VEHICLE FOR SALE
No.:
Vehicle Type: Ambulance
Brand Name: FOTON
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
The Foton TOANO Ambulance delivers critical care transport with its Cummins ISF 2.8L turbocharged engine producing 120kW power and 360Nm torque. The 5990×2000×2415mm body provides ample space for medical equipment, while 215/75R16LT tires ensure road stability. Standard features include ABS+EBD, central locking, and front/rear A/C (optional). With 3499kg GVW capacity and Euro II/V/IV options, it meets diverse emergency service requirements.
Technical Specifications Table
Parameter | TOANO Ambulance | Comparison: View C2 Ambulance |
|---|---|---|
Engine | Cummins ISF 2.8 (120kW/360Nm) | 4JB1T Diesel (70kW) |
Displacement | 2780ml | 2771ml |
Seating Capacity | 3 (Driver + 2 medical staff) | 3 |
Gross Vehicle Weight | 3499kg | 3150kg |
Wheelbase | 3750mm | 2570/3050mm |
Overall Dimensions | 5990×2000×2415mm | 4840-5320×1695×2240mm |
Emission Standard | Euro II/V/IV | Euro II/IV |
Tire Specification | 215/75R16LT | 195R15C |
Standard Medical Features:
•
Patient Compartment:
•
3-person configuration (driver + 2 EMS personnel)
•
Integrated medical equipment mounting system
•
Emergency lighting and siren provisions
•
Safety Systems:
•
ABS+EBD with disc/drum brakes
•
Reinforced body structure
•
High-mounted brake light
•
Accessibility:
•
Wide side access doors
•
Rear double doors
•
Electric windows (front)
Performance Metrics:
Metric | Specification |
|---|---|
Max Speed | ≥143km/h |
Fuel Consumption | ≤9.5L/100km |
Gradeability | ≥35% |
Turning Radius | ≤13.5m |
Approach Angle | ≥18.8° |
Departure Angle | ≥15.5° |
