FOTON TM5 DOUBLE CABIN TRUCK 15L/22L ENGINES 28-35T PAYLOAD
No.:
Vehicle Type: mini flat truck
Brand Name: FOTON
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
The Foton TM5 double cabin truck delivers flexible power options with 1.5L gasoline (82kW/142Nm) or 2.2L diesel (65kW/240Nm) engines supporting 2.8-3.5T payloads. The 1620mm wide cab and 3300mm cargo length make it ideal for urban logistics, featuring hydraulic power steering, ABS brakes, and 185R14LT tires.
Technical Specifications
Category | Gasoline Version | Diesel Version |
|---|---|---|
Engine | DAM15L 1.5L (82kW) | 4A2-88C53 2.2L (65kW) |
Torque | 142Nm @ 4500rpm | 240Nm @ 2000rpm |
Transmission | 5-speed Manual | 5-speed Manual |
GVW | 2,690-3,490kg | 3,404kg |
Cargo Area | 3300×1710×360mm | 3100×1710×360mm |
Brakes | Front Disc + Rear Drum | Front Disc + Rear Drum |
Tires | 185R14LT (6+1) | 185R14LT (6+1) |
Key Features
Powertrain Options
1.5L gasoline or 2.2L diesel engines
5-speed manual transmission
Load Capacity
Up to 3.5T GVW capacity
3300mm long cargo bed
Comfort & Safety
1620mm wide double cabin
Hydraulic power steering
ABS braking system
Versatility
Single/Double row cab options
Left/Right hand drive available
Standard Equipment
ABS (diesel models)
Front disc brakes
Leaf spring suspension
185R14LT tires
