FAW Jiefang 5-24 m³ Water Sprinkler Truck Chassis 110-350 HP for Sale – All-Volume Reference Guide
No.:
Vehicle Type: Water Tank Truck
Brand Name: FAW
Person in charge: William Du
Cel: 8618669778647
Whatsapp: 8618669778647
E-mail: sales22@chinatruck.cc
FREE GET QUOTE
Details
FAW Jiefang 5-24 m³ Water Sprinkler Truck Chassis 110-350 HP Reference Guide
Chassis Matching Matrix
复制
| Volume (m³) | Wheelbase (mm) | Engine (HP) | Tyres | Rear Axle (T) | Rear Overhang (mm) |
|---|---|---|---|---|---|
| 5 | 3 300 | 110–130 | 700R16 | 3.7 | 1 700 |
| 8–10 | 3 800 | 150/190 | 7.50R16 / 8.25R16 | 5.5 / 7 | 2 200 / 2 400 |
| 12–14 | 4 000 / 4 500 / 4 700 | 190 / 240 | 900R20 / 10.00R20 | 9 / 10 | 2 450 / 2 500 / 2 750 |
| 16 | 4 700 / 5 000 / 5 200 | 200 / 260 | 10.00R20 | 10 | 2 550 / 2 750 |
| 20–22 | 4 350+1 350 / 4 600+1 350 | 280 / 350 | 11.00R20 | Dual 10 | 3 100 / 3 300 |
| 24 | 4 750+1 400 | 300 / 350 | 11.00R20 | Dual 10 | 3 100 / 3 300 |
PTO Options
Factory-mounted or retrofit flange/spline PTO on all models.
Contact us for chassis, body build or turnkey sprinklers!
