Wheelbase

3450 1450mm

Overall length

8.84 m

Overall width

2.5 m

Overall height

3.63 m

Curb weight

12630kg

Rated quality

12240kg

Track

Front track: 1995    Rear track: 1800/1800mm

Front / rear overhang

1410/2530(mm)

The total mass

25000kg

Place of Origin

Baotou

Approach angle

26 degrees

Departure angle

15 degrees

Engine

Engine Model:Weichai WP10.375,

Number of cylinders:6,

Fuel type:Diesel fuel

Displacement:9.726L

Emission standards:Country, three

Horsepower:375hp

Maximum output power:276KW

Torque:1460N · m

Maximum torque speed:1200-1600

Engine Type:Water-cooled, four-stroke with the exhaust valve brake,

direct injection, turbocharged and intercooled

Transmission

Transmission Type:9T-180

Chassis

Axle load: 7000/18000 (and biaxial loading)

Number of axes: 3

spring: 10/13

Tire

Number of tires:10+1(spare tire)

Tire Size:12.00-20

Tank

Fuel tank capacity:300L

Remarks

You can optional front fence boards, air conditioning, sun visor. Mixing volume: 8 m3
