Wheelbase

3800 1450mm

Overall length

9.3 m

Cab

Long

Overall width

2.5 m

Overall height

3.9 m

Curb weight

12870kg

Rated quality

12000kg

Track

Front track: 1995    Rear track: 1800/1800mm

Front / rear overhang

1410/2640(mm)

The total mass

25000kg

Place of Origin

Baotou

Approach angle

26 degrees

Departure angle

20 degrees

Engine

Engine Model: Weichai WP10.340E32,

Number of cylinders:6,

Fuel type: Diesel fuel

Displacement:9.726L

Emission standards: Euro III

Horsepower:340hp

Maximum output power:250KW

Torque:1250N · m

Engine Type: Water-cooled, four-stroke with the exhaust valve brake,

direct injection, turbocharged and intercooled

Transmission

Transmission Type:9T-1680

Chassis

Front Axle:7.5ton

Drive Axle:13Ton double rear axle

Ratio:5.263

Steering

TAS85

Tire

Number of tires:10+1(spare tire)

Tire Size:12.00R20

Tank

Fuel tank capacity:300L

Remarks

:9 cubic meters. Italy TOP P68 reducer, 089 pumps, motors.
