BeiBen 8x4 380hp Fence Cargo Truck and Chassis

No.: Kobe-1607-29

Vehicle Type: Cargo Truck

Brand Name: BEIBEN

Beiben Trucks

Person in charge: Kobe Zhang

Cel: 0086 176 6971 7516

Whatsapp: 8617669717516

E-mail: sales30@chinatruck.cc

FREE GET QUOTE
ERWEIMA

Details

Person in charge: Mr.Kobe Zhang
Tel: 0086-532-80903896-807
Cel: 0086-17669717516
E-mail: sales30@chinatruck.cc

BEIBEN 8X4 CARGO TRUCK

Wheel base  (mm)

1950+4450+1450

Curb weight kg

11660

Engine


Model

WP10.380E32

Power, max   kw/rpm

279/2200

Max torque(Nm/rpm)

1160/1100-1600

Emission standard

EUROII

Fuel tanker capacity   L

300

Clutch

Model

GFX420, Single dry frictional disc,Hydraulic boosting

Gearbox

Mode

12JS200T

Transfer-case

VG1400(Benz technical,made by BEIBEN AXLE)

Brake system

Service brake

Brake gap can be adjusted automatically, double circulation air brake system

Assistant brake

Engine exhaust brake

Park brake

Potential springs pressing on middle and rear wheels

Steering system

Model

ZF8098

Frame of vehicle

Fish belly shape, variable width, variable section side beam structure

Front axle (Mercedes Benz  Technology)

Double-shoe pneumatic brake, non-driving steering axle


Middle and Rear axle (Mercedes Benz Technology)

Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle


Tyre

12.00R20

Electrical system

Battery

2X12V/135Ah

Generator

28V-35A

Starter

5.4Kw/24V

Cab

Short cab, made by full steel material, anticrash performance can be ensured by double hollow chamber structure.Inner A/C
