SHACMAN CUMMINS Engine 345hp 8x4 heavy duty dump truck

No.: David-08

Vehicle Type: Dump Truck

Brand Name: SHACMAN

Shacman Trucks

Person in charge: David Ma

Tel: 0086 532 6608 7516

Cel: 0086 181 5320 9783

E-mail: sales20@chinatruck.cc

FREE GET QUOTE

Details

Person in charge: Mr.David Ma

Tel: 0086-532-66087516

Cel: 0086-18153209783

E-mail: sales20@chinatruck.cc

SHACMAN CUMMINS 345hp 8x4 heavy duty dump truck


SHACMAN

F3000

8*4

Dump Truck


Traction type

LHD

Drive System

8x4

Cabin

F3000 Flat Cabin, one sleeper, Air Conditioner

Engine

Brand

CUMMINS

Model

ISME345 30  EuroIII

Rated power

345hp

Engine displacement

10.8 liters

Gearbox

FAST 10 Speeds (10JSD180)

Clutch

Ф430 Diaphragm type

Steering

ZF technology

Axle

Front

7.5 Ton Man axle

Rear

16 Ton MAN double reduction axle, ratio:5.262

Max. running speed (km/h)

77

Tire

12.00R20

Fuel tank

300L(Aluminum)

Kerb weight (kg)

14600

Total mass (kg)

31000

Wheel base (mm)

1800+3575+1400

Overhang (mm) (front/rear)

1525/2055

Track (mm) (front/rear)

2036/1850

Approach / departure angle(°)

28/30

DimensionsL*W*H(mm)

Overall

10729x2500x3500

Dump body

7000~7200x2300x1500

Thickness (mm)

Bottom 8 , front6mm,side 4

Hydraulic lifting system

 Front lifting

Options

  Front lifting(HYVA)
