Clutch

Single-plate dry coil-spring clutch, diameter 420mm,hydraulically operating with air assistance

Transmission

HW13710, 10 forward, 2 reverse

Propeller Shaft

Double universal joint propeller shaft with gear-shaped coupling flange

Front Axle

HF7

Rear Axle

MCY13Q

Chassis

Frame :U-profile parallel ladder frame with section of 300×80×8 mm, all cold riveted cross members

Front suspension: 9 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer

Rear suspention:12 leaf semi-elliptic spring with bogie springs, stabilizer

Aluminum fuel tank: 400L capacity with locking fuel cap, fitted to the off side of the chassis

Fifth wheel size: 2 inch

Option: 3.5 inch fifth wheel

Steering

ZF8098,hydraulic steering with power assistance

Ratio:22.2-26.2

Brakes

Service brake: dual circuit compressed air brake

Parking brake (emergency brake):spring energy, compressed air operating on rear wheels

Auxiliary brake: engine exhaust valve brake

Option: ABS

Wheels & Tyres

Rims:80R22.5,10 hole-steel

Tyres:12.00R22.5 tubeless tire

Option:12R20 tube,12.00-24 tube

Driver’s Cab

HW79 high roof cab, all-steel forward control, 55°hydraulically tiltable to the front, 2-arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, adjustable air suspension driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, exterior sun visor, adjustable roof flap, stereo radio/cassette recorder, safety belts, adjustable steering wheel, air horn, air conditioner and double bunks, with 4-point support fully floating suspension + shock absorbers with tranverse stabilizer

Instrument Panel

Active check central controller with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators of compressed air pressure, coolant temperature, engine oil pressure and battery charging

Dimensions in mm

Wheel base 3825+1350

70

Overall dimension(L x W x H mm) 7390×2496×3668

Weight in kg

Dead weight 9210

Gross vehicle weight 25000
