Lifting Structure

Rated Lifting weight

kg

13765

Max. Lifting weight of original place

kg

18000

Max. Lifting weight of full extension boom

kg

8000

Rated towing weight

kg

44000

Max. Designed towing weight

kg

60000

Effective length of boom

mm

3350

Extension traveling of boom

mm

1700

Folding angle of boom

°

90

Under lift Structure

Max. Rated hanging weight

kg

25000

The height from hook to the ground

mm

13430

Max. Extension traveling of lifting boom

mm

6000

Rotation angle

°

360

Numbers of winch

piece

2

Rated pulling power of winch

kg

2×15000

Dia. Of steel cable

mm

22.4

Length of steel cable

m

40

Min. Speed of steel cable

m/min

4

Rotation angle

°

65

Vehicle

Parameters

External dimension

mm

10741×2500×3366

Chassis model

FM400 84RB

Drive

8×4

Axle base

mm

1995+4405+1370

The whole weight of empty load

kg

30040

Load of front axle of empty load

kg

14380

Load of rear axle of empty load

kg

15660

The whole weight of full load

kg

44000

Load of front axle of full load

kg

9000/9000

Load of rear axle of full load

kg

13000/13000

Wheel base (front/rear axle)

mm

2019/1834

Front suspension

mm

1362

Rear suspension

mm

935

Approach angle

º

16.6

Departure angle

º

20

Min. Turning diameter

m

24.6

Min. Ground clearance

mm

306

Max. Speed

km/h

99

Grade ability

%

30

Gas consumption per one hundred miles(diesel oil)

L

35.4

Engine model

-

D13

Engine emission

L

12.8

Rated power

kw/r/min

294/1400～1800

Torque

n·m/r/min

2000/1050～1400

Fuel type

Diesel

Standard of emission

EN III

Tire size

315/80R22.5

Persons

3
