3 Axles Skeleton 40ft Container Semitrailer for sale

No.: vicky-A001

Vehicle Type: Container Semi-trailer

Brand Name: LUFENG

CIMC Trailer

Person in charge: Vicky Wang

Tel: 0086 532 6608 7516

Cel: 0086 181 5320 6873

E-mail: sales3@chinatruck.cc

FREE GET QUOTE

Details

Person in charge: Ms.Vicky Wang
Cel: 0086-18153206873
E-mail: sales3@chinatruck.cc

2 Axles Skeleton 20 foot Container Semitrailer

Tare Weight

3400kg

Payload

35000kg

Total Weight

38400kg

Overall Length

7200mm

Overall Width

2480mm

Overall Height

1570mm

Wheel track

1840mm

Wheelbase

4450+1310mm


_ 2 Axle Container Semitrailer Skeletal Specification:


Main Frame

Heavy duty and extra durability designed; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes.

Axle

Two units L1 brand 13T axle

Suspension

L1 brand 2-axle mechanical suspension

Leaf Spring

Four sets reliable local brand, 8-piece leaf spring, 16*90mm

King Pin

One unit 2” bolt-in kingpin, standard

Landing Gear

Two-speed, manual operation, heavy duty SAF-holland 19” linked landing gear

Wheel Rim

8 units 8.25-22.5 rim

Tire

8 units 11R22.5 tire

Twist Lock

4nos.

Spare Wheel Carrier

One set of spare wheel carrier including a riser.

Pneumatic Braking System

One units of WABCO RE 4 relay valve; four units of T30/30 spring brake chamber; one unit of reliable local brand 45L air tank; two units of reliable local brand standard coppery air-connector.

Electrical System

One unit of JAEGER POWAY, 24V 7-pin ISO 1185 socket; two sets of reliable, local brand standard rear light, turn light, rear reflector, side light, side reflector etc. One set of DAFA(brand) 6-core standard Cable.

Painting

Sand blasting before painting; one coats of primer, anti corrosion;

two coat of finish painting; color advised by client.

Accessory

One box with a set of standard trailer tool


_ Terms and Conditions :


1. This quotation will serve as base of our later P/I or contract.

2. Lead Time:  **days after downpayment reaches the seller(adjusted by the quantity and model).

3. Payment Terms: T/T 30% before SOP(Start Of Production), and T/T 70% balance before shipment.

4.Expiry date: This quotation valid for one week only.

5.This offer is subjected to seller's final confirmation .

7. Quality level: excellent quality for international market, made in China, WONDEE brand

8. Certificate: ISO9001; TS16949; COC; PVOC; CIQ; SONCAP; BV; C/O; FORME.

9. Area suitable: America,Europe,Asia


_ Semi Trailer Features:


1.Apply to the transport loose cargo light, soft, with a low center of gravity and light weight, the quality of the utilization factor, carrying capacity and other characteristics

2. Overall assembly and disassembly convenient, can be more than one car, van, car warehouse gate, tailgate car at the same time.

3.Innovative design, tailored to local transport environment analysis on the basis of full understanding of, learn from the advanced design concept, many innovative.

4.advanced means of production technology and perfect testing equipment to protect the the product overall structure is reasonable, reliable performance.

5. frame body Q345B high strength structure steel, automatic submerged arc welding throughout beams, and other cross-section main stringers structure for optimum carrying effect.
6. Well-known brand axles, suspension systems, high performance, and reliable to use, to ensure the good performance of the vehicle.
7.Full braking and electrical systems at home and abroad in accordance with ISO standard, optional ABS system, braking, lighting is absolutely safe and reliable.
8.frame overall spray primer treatment, paint spraying fine surface quality of maritime anti-corrosion standards.

9.Products fully comply with relevant national standard GB1589, GB/T6420, at the same time to meet the individual needs of customers.


_ More Information:


* We supply 20 feet and 40 feet Flatbed Semi-Trailer.


* The semi-trailer could beFlatbed and skeletal, 2 axle and 3 axle according to different demands.


* Our factory will carry on technological transformation to the products constantly, adopt the new technology.


* The high quality material perfects the function of use of the products and product quality constantly.


* Satisfy the masses of customers' request with the hospitable service and sincere management.

FREE Inquiry Now

If you have any questions, feedback or comments, please fill out the form below and we will reply you back as soon as possible.
